QUANTUM
™
LX EVAPORATOR CONTROL PANEL
COMMUNICATIONS SETUP
090.610-CS (MAY 2016)
Page 62
MODE VALUES: (Read Only, Continued)
Frick®
Address
AB
Address
Modbus
Address
Description of Data
Read/
Write
Value Codes
12450-
12479
N40:4450-
N40:4479
52451-52480 Monday Schedule 1 (Zones 1 – 30)
R
0 = Mode Stand By
1 = Mode 1
2 = Mode 2
3 = Mode 3
4 = Mode 4
12480-
12509
N40:4480-
N40:4509
52481-52510 Monday Schedule 2 (Zones 1 – 30)
12510-
12539
N40:4510-
N40:4539
52511-52540 Monday Schedule 3 (Zones 1 – 30)
12540-
12569
N40:4540-
N40:4569
52541-52570 Monday Schedule 4 (Zones 1 – 30)
12570-
12599
N40:4570-
N40:4599
52571-52600 Monday Schedule 5 (Zones 1 – 30)
12600-
12629
N40:4600-
N40:4629
52601-52630 Monday Schedule 6 (Zones 1 – 30)
12630-
12659
N40:4630-
N40:4659
52631-52660 Monday Schedule 7 (Zones 1 – 30)
12660-
12689
N40:4660-
N40:4689
52661-52690 Monday Schedule 8 (Zones 1 – 30)
12690-
12719
N40:4690-
N40:4719
52691-52720 Tuesday Schedule 1 (Zones 1 – 30)
12720-
12749
N40:4720-
N40:4749
52721-52750 Tuesday Schedule 2 (Zones 1 – 30)
12750-
12779
N40:4750-
N40:4779
52751-52780 Tuesday Schedule 3 (Zones 1 – 30)
12780-
12809
N40:4780-
N40:4809
52781-52810 Tuesday Schedule 4 (Zones 1 – 30)
12810-
12839
N40:4810-
N40:4839
52811-52840 Tuesday Schedule 5 (Zones 1 – 30)
12840-
12869
N40:4840-
N40:4869
52841-52870 Tuesday Schedule 6 (Zones 1 – 30)
12870-
12899
N40:4870-
N40:4899
52871-52900 Tuesday Schedule 7 (Zones 1 – 30)
12900-
12929
N40:4900-
N40:4929
52901-52930 Tuesday Schedule 8 (Zones 1 – 30)
12930-
12959
N40:4930-
N40:4959
52931-52960 Wednesday Schedule 1 (Zones 1 – 30)
12960-
12989
N40:4960-
N40:4989
52961-52990 Wednesday Schedule 2 (Zones 1 – 30)
12990-
13019
N40:4990-
N40:5019
52991-53020 Wednesday Schedule 3 (Zones 1 – 30)
13020-
13049
N40:5020-
N40:5049
53021-53050 Wednesday Schedule 4 (Zones 1 – 30)
13050-
13079
N40:5050-
N40:5079
53051-53080 Wednesday Schedule 5 (Zones 1 – 30)
13080-
13109
N40:5080-
N40:5109
53081-53110 Wednesday Schedule 6 (Zones 1 – 30)
13110-
13139
N40:5110-
N40:5139
53111-53140 Wednesday Schedule 7 (Zones 1 – 30)
13140-
13169
N40:5140-
N40:5169
53141-53170 Wednesday Schedule 8 (Zones 1 – 30)
To Next Page
