QUANTUM
™
LX EVAPORATOR CONTROL PANEL
COMMUNICATIONS SETUP
090.610-CS (MAY 2016)
Page 63
MODE VALUES: (Read Only, Continued)
Frick®
Address
AB
Address
Modbus
Address
Description of Data
Read/
Write
Value Codes
13170-
13199
N40:5170-
N40:5199
53171-53200 Thursday Schedule 1 (Zones 1 – 30)
R
0 = Mode Stand By
1 = Mode 1
2 = Mode 2
3 = Mode 3
4 = Mode 4
13200-
13229
N40:5200-
N40:5229
53201-53230 Thursday Schedule 2 (Zones 1 – 30)
13230-
13259
N40:5230-
N40:5259
53231-53260 Thursday Schedule 3 (Zones 1 – 30)
13260-
13289
N40:5260-
N40:5289
53261-53290 Thursday Schedule 4 (Zones 1 – 30)
13290-
13319
N40:5290-
N40:5319
53291-53320 Thursday Schedule 5 (Zones 1 – 30)
13320-
13349
N40:5320-
N40:5349
53321-53350 Thursday Schedule 6 (Zones 1 – 30)
13350-
13379
N40:5350-
N40:5379
53351-53380 Thursday Schedule 7 (Zones 1 – 30)
13380-
13409
N40:5380-
N40:5409
53381-53410 Thursday Schedule 8 (Zones 1 – 30)
13410-
13439
N40:5410-
N40:5439
53411-53440 Friday Schedule 1 (Zones 1 – 30)
13440-
13469
N40:5440-
N40:5469
53441-53470 Friday Schedule 2 (Zones 1 – 30)
13470-
13499
N40:5470-
N40:5499
53471-53500 Friday Schedule 3 (Zones 1 – 30)
13500-
13539
N40:5500-
N40:5539
53501-53540 Friday Schedule 4 (Zones 1 – 30)
13530-
13559
N40:5530-
N40:5559
53531-53560 Friday Schedule 5 (Zones 1 – 30)
13560-
13589
N40:5560-
N40:5589
53561-53590 Friday Schedule 6 (Zones 1 – 30)
13590-
13619
N40:5590-
N40:5619
53591-53620 Friday Schedule 7 (Zones 1 – 30)
13620-
13649
N40:5620-
N40:5649
53621-53650 Friday Schedule 8 (Zones 1 – 30)
13650-
13679
N40:5650-
N40:5679
53651-53680 Saturday Schedule 1 (Zones 1 – 30)
13680-
13709
N40:5680-
N40:5709
53681-53710 Saturday Schedule 2 (Zones 1 – 30)
13710-
13739
N40:5710-
N40:5739
53711-53740 Saturday Schedule 3 (Zones 1 – 30)
13740-
13769
N40:5740-
N40:5769
53741-53770 Saturday Schedule 4 (Zones 1 – 30)
13770-
13799
N40:5770-
N40:5799
53771-53800 Saturday Schedule 5 (Zones 1 – 30)
13800-
13829
N40:5800-
N40:5829
53801-53830 Saturday Schedule 6 (Zones 1 – 30)
13830-
13859
N40:5830-
N40:5859
53831-53860 Saturday Schedule 7 (Zones 1 – 30)
13860-
13889
N40:5860-
N40:5889
53861-53890 Saturday Schedule 8 (Zones 1 – 30)
To Next Page
