Frick QUANTUM LX - Page 64

QUANTUM
™
LX EVAPORATOR CONTROL PANEL
COMMUNICATIONS SETUP
090.610-CS (MAY 2016)
Page 64
MODE VALUES: (Read Only, Continued)
Frick®
Address
AB
Address
Modbus
Address
Description of Data
Read/
Write
Value Codes
14490-
14519
N40:6490-
N40:6519
14491-14520
Aux. Analog Input #1, Alarm Congu-
ration (Zones 1 – 30)
R
0 = Auxiliary Analog Disable
1 = Auxiliary Analog When Running
2 = Auxiliary Analog Always
14520-
14549
N40:6520-
N40:6549
14521-14550
Aux. Analog Input #2, Alarm Congu-
ration (Zones 1 – 30)
14550-
14579
N40:6550-
N40:6579
14551-14580
Aux. Analog Input #3, Alarm Congu-
ration (Zones 1 – 30)
14580-
14609
N40:6580-
N40:6609
14581-14610
Aux. Analog Input #4, Alarm Congu-
ration (Zones 1 – 30)
14610-
14639
N40:6610-
N40:6639
14611-14640
Aux. Analog Input #5, Alarm Congu-
ration (Zones 1 – 30)
14640-
14669
N40:6640-
N40:6669
14641-14670
Aux. Analog Input #6, Alarm Congu-
ration (Zones 1 – 30)
14670-
14699
N40:6670-
N40:6699
14671-14700
Aux. Analog Input #7, Alarm Congu-
ration (Zones 1 – 30)
14700-
14729
N40:6700-
N40:6729
14701-14730
Aux. Analog Input #8, Alarm Congu-
ration (Zones 1 – 30)
14730-
14759
N40:6730-
N40:6759
14731-14760
Aux. Analog Input #9, Alarm Congu-
ration (Zones 1 – 30)
14760-
14789
N40:6760-
N40:6789
14761-14790
Aux. Analog Input #10, Alarm Congu-
ration (Zones 1 – 30)
