QUANTUM
™
LX EVAPORATOR CONTROL PANEL
COMMUNICATIONS SETUP
090.610-CS (MAY 2016)
Page 65
MODE VALUES: (Read Only, Continued)
Frick®
Address
AB
Address
Modbus
Address
Description of Data
Read/
Write
Value Codes
14790-
14819
N40:6790-
N40:6819
44791-44820
Auxiliary Digital Output #1 Mapping
(Zones 1 – 30)
R
None
0 = Return Air Temperature
2 = Humidity
3 = User Dened Analog In #1
4 = User Dened Analog In #2
5 = User Dened Analog In #3
6 = User Dened Analog In #4
7 = User Dened Analog In #5
8 = User Dened Analog In #6
9 = User Dened Analog In #7
10 = User Dened Analog In #8
11 = User Dened Analog In #9
12 = User Dened Analog In #10
21 = Ammonia Sensor 1
22 = Ammonia Sensor 2
23 = Ammonia Sensor 3
24 = Ammonia Sensor 4
25 = Ammonia Sensor 5
26 = Ammonia Sensor 6
27 = Ammonia Sensor 7
28 = Ammonia Sensor 8
29 = Ammonia Sensor 9
30 = Ammonia Sensor 10
31 = Ammonia Sensor 11
32 = Ammonia Sensor 12
33 = Ammonia Sensor 13
34 = Ammonia Sensor 14
35 = Ammonia Sensor 15
36 = Ammonia Sensor 16
37 = Ammonia Sensor 17
38 = Ammonia Sensor 18
40 = Ammonia Sensor 20
41 = Ammonia Sensor 21
42 = Ammonia Sensor 22
43 = Ammonia Sensor 23
44 = Ammonia Sensor 24
45 = Ammonia Sensor 25
49 = Ammonia Sensor 26
47 = Ammonia Sensor 27
48 = Ammonia Sensor 28
49 = Ammonia Sensor 29
50 = Ammonia Sensor 30
14820-
14849
N40:6820-
N40:6849
44821-44850
Aux. Digital Output #2 Mapping (Zones
1 – 30)
14850-
14879
N40:6850-
N40:6879
44851-44880
Auxiliary Digital Output #3 Mapping
(Zones 1 – 30)
14880-
14909
N40:680-
N40:6909
44881-44910
Auxiliary Digital Output #4 Mapping
(Zones 1 – 30)
14910-
14939
N40:6910-
N40:6939
44911-44940
Auxiliary Digital Output #5 Mapping
(Zones 1 – 30)
14940-
14969
N40:6940-
N40:6969
44941-44970
Auxiliary Digital Output #6 Mapping
(Zones 1 – 30)
14970-
14999
N40:6970-
N40:6999
44971-45000
Auxiliary Digital Output #7 Mapping
(Zones 1 – 30)
15000-
15029
N40:7000-
N40:7029
45001-45030
Auxiliary Digital Output #8 Mapping
(Zones 1 – 30)
15030-
15059
N40:7030-
N40:7059
45031-45060
Auxiliary Digital Output #9 Mapping
(Zones 1 – 30)
15060-
15089
N40:7060-
N40:7089
45061-45090
Auxiliary Digital Output #10 Mapping
(Zones 1 – 30)
15090-
15119
N40:7090-
N40:7119
45091-45120
Auxiliary Digital Output #1 Congura-
tion (Zones 1 – 30)
15120-
15149
N40:7120-
N40:7149
45121-45150
Auxiliary Digital Output #2 Congura-
tion (Zones 1 – 30)
15150-
15179
N40:7150-
N40:7179
45151-45180
Auxiliary Digital Output #3 Congura-
tion (Zones 1 – 30)
15180-
15209
N40:7180-
N40:7209
45181-45210
Auxiliary Digital Output #4 Congura-
tion (Zones 1 – 30)
15210-
15239
N40:7210-
N40:7239
45211-45240
Auxiliary Digital Output #5 Congura-
tion (Zones 1 – 30)
15240-
15269
N40:7240-
N40:7269
45241-45270
Auxiliary Digital Output #6 Congura-
tion (Zones 1 – 30)
15270-
15299
N40:7270-
N40:7299
45271-45300
Auxiliary Digital Output #7 Congura-
tion (Zones 1 – 30)
15300-
15329
N40:7300-
N40:7329
45301-45330
Auxiliary Digital Output #8 Congura-
tion (Zones 1 – 30)
15330-
15359
N40:7330-
N40:7359
45331-45360
Auxiliary Digital Output #9 Congura-
tion (Zones 1 – 30)
15360-
15389
N40:7360-
N40:7389
45361-45390
Auxiliary Digital Output #10 Congura-
tion (Zones 1 – 30)
