Frick QUANTUM LX - Page 66

QUANTUM
™
LX EVAPORATOR CONTROL PANEL
COMMUNICATIONS SETUP
090.610-CS (MAY 2016)
Page 66
MODE VALUES: (Read Only, Continued)
Frick®
Address
AB
Address
Modbus
Address
Description of Data
Read/
Write
Value Codes
15390-
15419
N40:7390-
N40:7419
45391-45420
Auxiliary Digital Output #1 Action
(Zones 1 – 30)
R
0 = Greater Than
1 = Less Than
15420-
15449
N40:7420-
N40:7449
45421-45450
Auxiliary Digital Output #2 Action
(Zones 1 – 30)
15450-
15479
N40:7450-
N40:7479
45451-45480
Auxiliary Digital Output #3 Action
(Zones 1 – 30)
15480-
15509
N40:7480-
N40:7509
45481-45510
Auxiliary Digital Output #4 Action
(Zones 1 – 30)
15510-
15539
N40:7510-
N40:7539
45511-45540
Auxiliary Digital Output #5 Action
(Zones 1 – 30)
15540-
15569
N40:7540-
N40:7569
45541-45570
Auxiliary Digital Output #6 Action
(Zones 1 – 30)
15570-
15599
N40:7570-
N40:7599
45571-45600
Auxiliary Digital Output #7 Action
(Zones 1 – 30)
15600-
15629
N40:7600-
N40:7629
45601-45630
Auxiliary Digital Output #8 Action
(Zones 1 – 30)
15630-
15659
N40:7630-
N40:7659
45631-45660
Auxiliary Digital Output #9 Action
(Zones 1 – 30)
15660-
15689
N40:7660-
N40:7689
45661-45690
Auxiliary Digital Output #10 Action
(Zones 1 – 30)
