Frick QUANTUM LX - Page 67

QUANTUM
™
LX EVAPORATOR CONTROL PANEL
COMMUNICATIONS SETUP
090.610-CS (MAY 2016)
Page 67
MODE VALUES: (Read Only, Continued)
Frick®
Address
AB
Address
Modbus
Address
Description of Data
Read/
Write
Value Codes
15690-
15719
N40:7690-
N40:7719
45691-45720
Auxiliary Analog Output #1 Mapping
(Zones 1 – 30)
R
None
0 = Return Air Temperature
2 = Humidity
3 = User Dened Analog In #1
4 = User Dened Analog In #2
5 = User Dened Analog In #3
6 = User Dened Analog In #4
7 = User Dened Analog In #5
8 = User Dened Analog In #6
9 = User Dened Analog In #7
10 = User Dened Analog In #8
11 = User Dened Analog In #9
12 = User Dened Analog In #10
21 = Ammonia Sensor 1
22 = Ammonia Sensor 2
23 = Ammonia Sensor 3
24 = Ammonia Sensor 4
25 = Ammonia Sensor 5
26 = Ammonia Sensor 6
27 = Ammonia Sensor 7
28 = Ammonia Sensor 8
29 = Ammonia Sensor 9
30 = Ammonia Sensor 10
31 = Ammonia Sensor 11
32 = Ammonia Sensor 12
33 = Ammonia Sensor 13
34 = Ammonia Sensor 14
35 = Ammonia Sensor 15
36 = Ammonia Sensor 16
37 = Ammonia Sensor 17
38 = Ammonia Sensor 18
39 = Ammonia Sensor 19
40 = Ammonia Sensor 20
41 = Ammonia Sensor 21
42 = Ammonia Sensor 22
43 = Ammonia Sensor 23
44 = Ammonia Sensor 24
45 = Ammonia Sensor 25
49 = Ammonia Sensor 26
47 = Ammonia Sensor 27
48 = Ammonia Sensor 28
49 = Ammonia Sensor 29
50 = Ammonia Sensor 30
15720-
15749
N40:7720-
N40:7749
45721-45750
Auxiliary Analog Output #2 Mapping
(Zones 1 – 30)
15750-
15779
N40:7750-
N40:7779
45751-45780
Auxiliary Analog Output #3 Mapping
(Zones 1 – 30)
15780-
15809
N40:7780-
N40:7809
45781-45810
Auxiliary Analog Output #4 Mapping
(Zones 1 – 30)
15810-
15839
N40:7810-
N40:7839
45811-45840
Auxiliary Analog Output #1 PI Direc-
tion (Zones 1 – 30
R
0 = Positive Acting
1 = Negative Acting
15840-
15869
N40:7840-
N40:7869
45841-45870
Auxiliary Analog Output #2 PI Direc-
tion (Zones 1 – 30
15870-
15899
N40:7870-
N40:7899
45871-
458909
Auxiliary Analog Output #3 PI Direc-
tion (Zones 1 – 30
15900-
15929
N40:7900-
N40:7929
45901-45930
Auxiliary Analog Output #4 PI Direc-
tion (Zones 1 – 30
