QUANTUM
™
LX EVAPORATOR CONTROL PANEL
COMMUNICATIONS SETUP
090.610-CS (MAY 2016)
Page 68
MODE VALUES: (Read Only, Continued)
Frick®
Address
AB
Address
Modbus
Address
Description of Data
Read/
Write
Value Codes
15930-
15959
N40:7930-
N40:7959
45931-45960
Auxiliary Analog Output #1 Congura-
tion (Zones 1 – 30)
R
0 = Disabled
1 = When Running
2 = Always
3 = Heating
4 = Cooling
5 = Defrost
15960-
15689
N40:7960-
N40:7689
45961-45690
Auxiliary Analog Output #2 Congura-
tion (Zones 1 – 30)
15990-
16019
N40:7990-
N40:8019
45991-46020
Auxiliary Analog Output #3 Congura-
tion (Zones 1 – 30)
16020-
16049
N40:8020-
N40:8049
46021-46050
Auxiliary Analog Output #4 Congura-
tion (Zones 1 – 30)
16050-
16079
N40:8050-
N40:8079
46051-46080
User Requested Zone On/Off (Zones
1 – 30)
R/W
0 = Zone Stand By
1 = Zone Running
16080-
16109
N40:8080-
N40:8109
46081-46110
User Requested Zone Active Mode
(Zones 1 – 30)
0 = Manual
1 = Automatic
2 = Input Control
16110-
16139
N40:8110-
N40:8139
46111-46140
User Requested Emergency Shutdown
(Zones 1 – 30)
0 = False
1 = True
