Frick QUANTUM LX - Page 76

QUANTUM
™
LX EVAPORATOR CONTROL PANEL
COMMUNICATIONS SETUP
090.610-CS (MAY 2016)
Page 76
SETPOINT VALUES: (Read/Write)
Frick®
Address
AB
Address
Modbus
Address
Description of Data
Default
Value
Units Min. Max.
34270-34299 N70:4270-N70:4299 74271-74300
Dehumidication Exit Low
Temperature Threshold Mode
3 (Zones 1 - 30)
28 Temp. -20 150
34300-34329 N70:4300-N70:4329 74301-74330
Dehumidication Exit Low
Temperature Threshold Mode
4 (Zones 1 - 30)
28 Temp. -20 150
34330-34359 N70:4330-N70:4359 74331-74360
Ammonia Shutdown Level
(Zones 1 - 30)
500 PPM 0 1,000,000
34390-34419 N70:4390-N70:4419 74391-74420
Variable Fan PI Setpoint Cool
Cycle Mode 1 (Zones 1 - 30)
40 Temp. -20 150
34420-34449 N70:4420-N70:4449 74421-74450
Variable Fan PI Setpoint Cool
Cycle Mode 2 (Zones 1 - 30)
40 Temp. -20 150
34450-34479 N70:4450-N70:4479 74451-74480
Variable Fan PI Setpoint Cool
Cycle Mode 3 (Zones 1 - 30)
40 Temp. -20 150
34480-34509 N70:4480-N70:4509 74481-74510
Variable Fan PI Setpoint Cool
Cycle Mode 4 (Zones 1 - 30)
40 Temp. -20 150
24540-34569 N70:4540-N70:4569 74541-74570
Variable Fan Proportional
Band Cool Cycle Mode 1
(Zones 1 - 30)
2
Temp.
(Magnitude)
0 100
34570-34599 N70:4570-N70:4599 74571-74600
Variable Fan Proportional
Band Cool Cycle Mode 2
(Zones 1 - 30)
2
Temp.
(Magnitude)
0 100
34600-34629 N70:4600-N70:4629 74601-74630
Variable Fan Proportional
Band Cool Cycle Mode 3
(Zones 1 - 30)
2
Temp.
(Magnitude)
0 100
34630-34659 N70:4630-N70:4659 74631-74660
Variable Fan Proportional
Band Cool Cycle Mode 4
(Zones 1 - 30)
2
Temp.
(Magnitude)
0 100
34690-34719 N70:4690-N70:4719 74691-74720
Variable Fan Integration Time
Cool Cycle Mode 1 (Zones
1 - 30)
30 Seconds 0 999
34720-34749 N70:4720-N70:4749 74721-74750
Variable Fan Integration Time
Cool Cycle Mode 2 (Zones
1 - 30)
30 Seconds 0 999
34750-34779 N70:4750-N70:4779 74751-74780
Variable Fan Integration Time
Cool Cycle Mode 3 (Zones
1 - 30)
30 Seconds 0 999
34780-34809 N70:4780-N70:4809 74781-74810
Variable Fan Integration Time
Cool Cycle Mode 4 (Zones
1 - 30)
30 Seconds 0 999
34840-34869 N70:4840-N70:4869 74841-74870
Variable Fan Maximum Speed
Cool Cycle Mode 1 (Zones
1 - 30)
100 Percent % 0 100
34870-34899 N70:4870-N70:4899 74871-74900
Variable Fan Maximum Speed
Cool Cycle Mode 2 (Zones
1 - 30)
100 Percent % 0 100
