Frick QUANTUM LX - Page 77

QUANTUM
™
LX EVAPORATOR CONTROL PANEL
COMMUNICATIONS SETUP
090.610-CS (MAY 2016)
Page 77
SETPOINT VALUES: (Read/Write)
Frick®
Address
AB
Address
Modbus
Address
Description of Data
Default
Value
Units Min. Max.
34900-34929 N70:4900-N70:4929 74901-74930
Variable Fan Maximum Speed Cool
Cycle Mode 3 (Zones 1 - 30)
100
Percent
%
0 100
34930-34959 N70:4930-N70:4959 74931-74960
Variable Fan Maximum Speed Cool
Cycle Mode 4 (Zones 1 - 30)
100
Percent
%
0 100
34990-35019 N70:4990-N70:5019 74991-75020
Fan Cycling On Time Cool Cycle
Mode 1 (Zones 1 - 30)
3 Minutes 0 1,000
35020-35049 N70:5020-N70:5049 75021-75050
Fan Cycling On Time Cool Cycle
Mode 2 (Zones 1 - 30)
3 Minutes 0 1,000
35050-35079 N70:5050-N70:5079 75051-75080
Fan Cycling On Time Cool Cycle
Mode 3 (Zones 1 - 30)
3 Minutes 0 1,000
35080-35109 N70:5080-N70:5109 75081-75110
Fan Cycling On Time Cool Cycle
Mode 4 (Zones 1 - 30)
3 Minutes 0 1,000
35140-35169 N70:5140-N70:5169 75141-75170
Fan Cycling Off Time Cool Cycle
Mode 1 (Zones 1 - 30)
27 Minutes 0 1,000
35170-35199 N70:5170-N70:5199 75171-75200
Fan Cycling Off Time Cool Cycle
Mode 2 (Zones 1 - 30)
27 Minutes 0 1,000
35200-35229 N70:5200-N70:5229 75201-75230
Fan Cycling Off Time Cool Cycle
Mode 3 (Zones 1 - 30)
27 Minutes 0 1,000
35230-35259 N70:5230-N70:5259 75231-75260
Fan Cycling Off Time Cool Cycle
Mode 4 (Zones 1 - 30)
27 Minutes 0 1,000
35290-35319 N70:5290-N70:5319 75291-75320
Hot Gas On Temperature Mode 1
(Zones 1 - 30)
25 Temp. -20 150
35320-35349 N70:5320-N70:5349 75321-75350
Hot Gas On Temperature Mode 2
(Zones 1 - 30)
25 Temp. -20 150
35350-35379 N70:5350-N70:5379 75351-75380
Hot Gas On Temperature Mode 3
(Zones 1 - 30)
25 Temp. -20 150
35380-35409 N70:5380-N70:5409 75381-75410
Hot Gas On Temperature Mode 4
(Zones 1 - 30)
25 Temp. -20 150
35440-35469 N70:5440-N70:5469 75441-75470
Hot Gas Off Temperature Mode 1
(Zones 1 - 30)
32 Temp. -20 150
35470-35499 N70:5470-N70:5499 75471-75500
Hot Gas Off Temperature Mode 2
(Zones 1 - 30)
32 Temp. -20 150
35500-35529 N70:5500-N70:5529 75501-75530
Hot Gas Off Temperature Mode 3
(Zones 1 - 30)
32 Temp. -20 150
35530-35559 N70:5530-N70:5559 75531-75560
Hot Gas Off Temperature Mode 4
(Zones 1 - 30)
32 Temp. -20 150
35590-35619 N70:5590-N70:5619 75591-75620
Fan On Temperature Heat Cycle
Mode 1 (Zones 1 - 30)
25 Temp. -20 150
35620-35649 N70:5620-N70:5649 75621-75650
Fan On Temperature Heat Cycle
Mode 2 (Zones 1 - 30)
25 Temp. -20 150
35650-35679 N70:5650-N70:5679 75651-75680
Fan On Temperature Heat Cycle
Mode 3 (Zones 1 - 30)
25 Temp. -20 150
35680-35709 N70:5680-N70:5709 75681-75710
Fan On Temperature Heat Cycle
Mode 4 (Zones 1 - 30)
25 Temp. -20 150
