Frick QUANTUM LX - Page 78

QUANTUM
™
LX EVAPORATOR CONTROL PANEL
COMMUNICATIONS SETUP
090.610-CS (MAY 2016)
Page 78
SETPOINT VALUES: (Read/Write)
Frick®
Address
AB
Address
Modbus
Address
Description of Data
Default
Value
Units Min. Max.
35740-35769 N70:5740-N70:5769 75741-75770
Fan Off Temperature Heat Cycle
Mode 1 (Zones 1 - 30)
32 Temp. -20 150
35770-35799 N70:5770-N70:5799 75771-75800
Fan Off Temperature Heat Cycle
Mode 2 (Zones 1 - 30)
32 Temp. -20 150
35800-35829 N70:5800-N70:5829 75801-75830
Fan Off Temperature Heat Cycle
Mode 3 (Zones 1 - 30)
32 Temp. -20 150
35830-35859 N70:5830-N70:5859 75831-75860
Fan Off Temperature Heat Cycle
Mode 4 (Zones 1 - 30)
32 Temp. -20 150
35860-35889 N70:5860-N70:5889 75861-75890
Heating Pumpout Time (Zones
1 - 30)
3 Min. 2 100
36010-36039 N70:6010-N70:6039 76011-76040
Heating Soft Hot Gas Time (Zones
1 - 30)
2 Min. 2 100
36160-36189 N70:6160-N70:6189 76161-76190
Heating Fan Delay Time (Zones
1 - 30)
0 Min. 0 100
36310-36339 N70:6310-N70:6339 76311-76340 Heating Bleed Time (Zones 1 - 30) 3 Min. 2 100
36460-36489 N70:6460-N70:6489 76461-76490
Heating Refreeze Condensate
Time (Zones 1 - 30)
3 Min. 2 100
36610-36639 N70:6610-N70:6639 76611-76640
Heating Pumpout Variable Fan
Speed (Zones 1 - 30)
60
Percent
%
0 100
36790-36819 N70:6790-N70:6819 76791-76820
Two Speed Fan High To Low Temp.
Heat Cycle Mode 1 (Zones 1 - 30)
30 Temp. -20 150
36820-36849 N70:6820-N70:6849 76821-76850
Two Speed Fan High To Low Temp.
Heat Cycle Mode 2 (Zones 1 - 30)
30 Temp. -20 150
36850-36879 N70:6850-N70:6879 76851-76880
Two Speed Fan High To Low Temp.
Heat Cycle Mode 3 (Zones 1 - 30)
30 Temp. -20 150
36880-36909 N70:6880-N70:6909 76881-76910
Two Speed Fan High To Low Temp.
Heat Cycle Mode 4 (Zones 1 - 30)
30 Temp. -20 150
36940-36969 N70:6940-N70:6969 76941-76970
Two Speed Fan Low To High Temp.
Heat Cycle Mode 1 (Zones 1 - 30)
27 Temp. -20 150
36970-36999 N70:6970-N70:6999 76971-77000
Two Speed Fan Low To High Temp.
Heat Cycle Mode 2 (Zones 1 - 30)
27 Temp. -20 150
37000-37029 N70:7000-N70:7029 77001-77030
Two Speed Fan Low To High Temp.
Heat Cycle Mode 3 (Zones 1 - 30)
27 Temp. -20 150
37030-37059 N70:7030-N70:7059 77031-77060
Two Speed Fan Low To High Temp.
Heat Cycle Mode 4 (Zones 1 - 30)
27 Temp. -20 150
37090-37119 N70:7090-N70:7119 77091-77120
Auxiliary Digital Input # 1 Alarm
Delay (Zones 1 - 30)
60 Sec. 0 1,000
37120-37149 N70:7120-N70:7149 77121-77150
Auxiliary Digital Input # 2 Alarm
Delay (Zones 1 - 30)
60 Sec. 0 1,000
37150-37179 N70:7150-N70:7179 77151-77180
Auxiliary Digital Input # 3 Alarm
Delay (Zones 1 - 30)
60 Sec. 0 1,000
