Frick QUANTUM LX - Page 79

QUANTUM
™
LX EVAPORATOR CONTROL PANEL
COMMUNICATIONS SETUP
090.610-CS (MAY 2016)
Page 79
SETPOINT VALUES: (Read/Write)
Frick®
Address
AB
Address
Modbus
Address
Description of Data
Default
Value
Units Min. Max.
37180-37209 N70:7180-N70:7209 77181-77210
Auxiliary Digital Input # 4 Alarm
Delay (Zones 1 - 30)
60 Sec. 0 1,000
37210-37239 N70:7210-N70:7239 77211-77240
Auxiliary Analog Input # 1 Low
Warning Delay (Zones 1 - 30)
60 Sec. 0 1,000
37240-37269 N70:7240-N70:7269 77241-77270
Auxiliary Analog Input # 2 Low
Warning Delay (Zones 1 – 30)
60 Sec. 0 1,000
37270-37299 N70:7270-N70:7299 77271-77300
Auxiliary Analog Input # 3 Low
Warning Delay (Zones 1 – 30)
60 Sec. 0 1,000
37300-37329 N70:7300-N70:7329 77301-77330
Auxiliary Analog Input # 4 Low
Warning Delay (Zones 1 – 30)
60 Sec. 0 1,000
37330-37359 N70:7330-N70:7359 77331-77360
Auxiliary Analog Input # 5 Low
Warning Delay (Zones 1 – 30)
60 Sec. 0 1,000
37360-37389 N70:7360-N70:7389 77361-77390
Auxiliary Analog Input # 6 Low
Warning Delay (Zones 1 – 30)
60 Sec. 0 1,000
37390-37419 N70:7390-N70:7419 77391-77420
Auxiliary Analog Input # 7 Low
Warning Delay (Zones 1 – 30)
60 Sec. 0 1,000
37420-37449 N70:7420-N70:7449 77421-77450
Auxiliary Analog Input # 8 Low
Warning Delay (Zones 1 – 30)
60 Sec. 0 1,000
37450-37479 N70:7450-N70:7479 77451-77480
Auxiliary Analog Input # 9 Low
Warning Delay (Zones 1 - 30)
60 Sec. 0 1,000
37480-37509 N70:7480-N70:7509 77481-77510
Auxiliary Analog Input # 10 Low
Warning Delay (Zones 1 – 30)
60 Sec. 0 1,000
37510-37539 N70:7510-N70:7539 77511-77540
Auxiliary Analog Input # 1 Low
Shutdown Delay (Zones 1 - 30)
60 Sec. 0 1,000
37540-37569 N70:7540-N70:7569 77541-77570
Auxiliary Analog Input # 2 Low
Shutdown Delay (Zones 1 - 30)
60 Sec. 0 1,000
37570-37599 N70:7570-N70:7599 77571-77600
Auxiliary Analog Input # 3 Low
Shutdown Delay (Zones 1 - 30)
60 Sec. 0 1,000
37600-37629 N70:7600-N70:7629 77601-77630
Auxiliary Analog Input # 4 Low
Shutdown Delay (Zones 1 - 30)
60 Sec. 0 1,000
37630-37659 N70:7630-N70:7659 77631-77660
Auxiliary Analog Input # 5 Low
Shutdown Delay (Zones 1 - 30)
60 Sec. 0 1,000
37660-37689 N70:7660-N70:7689 77661-77690
Auxiliary Analog Input # 6 Low
Shutdown Delay (Zones 1 - 30)
60 Sec. 0 1,000
37690-37719 N70:7690-N70:7719 77691-77720
Auxiliary Analog Input # 7 Low
Shutdown Delay (Zones 1 - 30)
60 Sec. 0 1,000
37720-37749 N70:7720-N70:7749 77721-77750
Auxiliary Analog Input # 8 Low
Shutdown Delay (Zones 1 - 30)
60 Sec. 0 1,000
37750-37779 N70:7750-N70:7779 77751-77780
Auxiliary Analog Input # 9 Low
Shutdown Delay (Zones 1 - 30)
60 Sec. 0 1,000
37780-37809 N70:7780-N70:7809 77781-77810
Auxiliary Analog Input # 10 Low
Shutdown Delay (Zones 1 - 30)
60 Sec. 0 1,000
37810-37839 N70:7810-N70:7839 77811-77840
Auxiliary Analog Input # 1 Low
Warning Setpoint (Zones 1 - 30)
20 None -10,000 10,000
37840-37869 N70:7840-N70:7869 77841-77870
Auxiliary Analog Input # 2 Low
Warning Setpoint (Zones 1 - 30)
20 None -10,000 10,000
37870-37899 N70:7870-N70:7899 77871-77900
Auxiliary Analog Input # 3 Low
Warning Setpoint (Zones 1 - 30)
(Zones 1 - 30)
20 None -10,000 10,000
37900-37929 N70:7900-N70:7929 77901-77930
Auxiliary Analog Input # 4 Low
Warning Setpoint
20 None -10,000 10,000
