Frick QUANTUM LX - Page 71

QUANTUM
™
LX EVAPORATOR CONTROL PANEL
COMMUNICATIONS SETUP
090.610-CS (MAY 2016)
Page 71
WARNING/SHUTDOWN VALUES: (Read Only)
Frick®
Address
AB
Address
Modbus
Address
Description of Data Value Codes
22301-22303 N50:2301-N50:2303 62302-62304 Analog Board 3, Port 3 Comm. Shutdown (Zones 22 – 24) 2402
22304-22306 N50:2304-N50:2306 62305-62307 Analog Board 4, Port 3 Comm. Shutdown (Zones 25 – 27) 2403
22307-22309 N50:2307-N50:2309 62308-62310 Analog Board 5, Port 3 Comm. Shutdown (Zones 28 – 30) 2404
22310-22312 N50:2310-N50:2312 62311-62313 Digital Board 1, Port 4 Reset (Zones 1 – 3) 2405
22313-22315 N50:2313-N50:2315 62314-62316 Digital Board 2, Port 4 Reset (Zones 4 – 6) 2406
22316-22318 N50:2316-N50:2318 62317-62319 Digital Board 3, Port 4 Reset (Zones 7 – 9) 2407
22319-22321 N50:2319-N50:2321 62320-62322 Digital Board 4, Port 4 Reset (Zones 10 – 12) 2408
22322-22324 N50:2322-N50:2324 62323-62325 Digital Board 5, Port 4 Reset (Zones 13 - 15) 2409
22325-22327 N50:2325-N50:2327 62326-62328 Digital Board 1, Port 3 Reset (Zones 16 – 17) 2415
22328-22330 N50:2328-N50:2330 62329-62331 Digital Board 2, Port 3 Reset (Zones 19 – 21) 2416
22331-22333 N50:2331-N50:2333 62332-62334 Digital Board 3, Port 3 Reset (Zones 22 – 24) 2417
22334-22336 N50:2334-N50:2336 62335-62337 Digital Board 4, Port 3 Reset (Zones 25 – 27) 2418
22337-22339 N50:2337-N50:2339 62338-62340 Digital Board 5, Port 3 Reset (Zones 28 – 30) 2419
22340-22342 N50:2340-N50:2342 62341-62343 Digital Board 6, Port 4 Reset (Zones 1 – 3) 2410
22343-22345 N50:2343-N50:2345 62344-62346 Digital Board 7, Port 4 Reset (Zones 4 – 6) 2411
22346-22348 N50:2346-N50:2348 62347-62349 Digital Board 8, Port 4 Reset (Zones 7 – 9) 2412
22349-22351 N50:2349-N50:2351 62350-62352 Digital Board 9, Port 4 Reset (Zones 10 – 12) 2413
22352-22354 N50:2352-N50:2354 62353-62355 Digital Board 10, Port 4 Reset (Zones 13 – 15) 2414
22355-22357 N50:2355-N50:2357 62356-62358 Digital Board 6, Port 3 Reset (Zones 16 – 18) 2420
22358-22360 N50:2358-N50:2360 62359-62361 Digital Board 7, Port 3 Reset (Zones 19 – 21) 2421
22361-22363 N50:2361-N50:2363 62362-623634 Digital Board 8, Port 3 Reset (Zones 22 – 24) 2422
22364-22366 N50:2364-N50:2366 62365-62367 Digital Board 9, Port 3 Reset (Zones 25 – 27) 2423
22367-22369 N50:2367-N50:2369 62368-62370 Digital Board 10, Port 3 Reset (Zones 28 – 30) 2424
22370-22399 N50:2370-N50:2399 62371-62400 Process Stopped (Zones 1 – 30) 2425
22400-22429 N50:2400-N50:2429 62401-62430 Ammonia Zone Sensor Fault, Map A (Zones 1 – 30) 12400-12429
22430-22459 N50:2430-N50:2459 62431-62460 Ammonia Zone Sensor Fault, Map B (Zones 1 – 30) 12430-12459
22460-22489 N50:2460-N50:2489 62461-62490 Ammonia Zone Sensor Fault, Map C (Zones 1 – 30) 12460-12489
22490-22519 N50:2490-N50:2519 62491-62520 Ammonia Zone Sensor Fault, Map D (Zones 1 – 30) 12490-12519
22520-22549 N50:2520-N50:2549 62521-62550 Ammonia Warning, Map A (Zones 1 – 30) 12520-12549
22550-22579 N50:2550-N50:2579 62551-62580 Ammonia Warning, Map B (Zones 1 – 30) 12550-12579
22580-22609 N50:2580-N50:2609 62581-62610 Ammonia Warning, Map C (Zones 1 – 30) 12580-12609
22610-22639 N50:2610-N50:2639 62611-62640 Ammonia Warning, Map D (Zones 1 – 30) 12610-12639
22640-22669 N50:2640-N50:2669 62641-62670 Ammonia Shutdown, Map A (Zones 1 – 30) 12640-12669
22670-22699 N50:2670-N50:2699 62671-62700 Ammonia Shutdown, Map B (Zones 1 – 30) 12670-12699
22700-22729 N50:2700-N50:2729 62701-62730 Ammonia Shutdown, Map C (Zones 1 – 30) 12700-12729
22730-22759 N50:2730-N50:2759 62731-62760 Ammonia Shutdown, Map D (Zones 1 – 30) 12730-12759
