Frick QUANTUM LX - Page 70

QUANTUM
™
LX EVAPORATOR CONTROL PANEL
COMMUNICATIONS SETUP
090.610-CS (MAY 2016)
Page 70
WARNING/SHUTDOWN VALUES: (Read Only)
Frick®
Address
AB
Address
Modbus
Address
Description of Data
Value
Codes
21740-21769 N50:1740-N50:1769 21741-21770 Auxiliary Analog Input #5 High Warning (Zones 1 – 30) 422
21770-21799 N50:1770-N50:1799 21771-21800 Auxiliary Analog Input #6 High Warning (Zones 1 – 30) 426
21800-21829 N50:1800-N50:1829 21801-21830 Auxiliary Analog Input #7 High Warning (Zones 1 – 30) 430
21830-21859 N50:1830-N50:1859 21831-21860 Auxiliary Analog Input #8 High Warning (Zones 1 – 30) 434
21860-21889 N50:1860-N50:1889 21861-21890 Auxiliary Analog Input #9 High Warning (Zones 1 – 30) 438
21890-21919 N50:1890-N50:1919 21891-21920 Auxiliary Analog Input #10 High Warning (Zones 1 – 30) 442
21920-21949 N50:1920-N50:1949 21921-21950 Auxiliary Analog Input #1 High Shutdown (Zones 1 – 30) 405
11950-21979 N111950-N50:1979 11951-21980 Auxiliary Analog Input #2 High Shutdown (Zones 1 – 30) 409
21980-22009 N50:1980-N50:2009 21981-22010 Auxiliary Analog Input #3 High Shutdown (Zones 1 – 30) 413
22010-22039 N50:2010-N50:2039 22011-22040 Auxiliary Analog Input #4 High Shutdown (Zones 1 – 30) 417
22040-22069 N50:2040-N50:2069 22041-22070 Auxiliary Analog Input #5 High Shutdown (Zones 1 – 30) 421
22070-22099 N50:2070-N50:2099 22071-22100 Auxiliary Analog Input #6 High Shutdown (Zones 1 – 30) 425
22100-22129 N50:2100-N50:2129 22101-22130 Auxiliary Analog Input #7 High Shutdown (Zones 1 – 30) 429
22130-22159 N50:2130-N50:2159 22131-22160 Auxiliary Analog Input #8 High Shutdown (Zones 1 – 30) 433
22160-22189 N50:2160-N50:2189 22161-22190 Auxiliary Analog Input #9 High Shutdown (Zones 1 – 30) 437
22190-22219 N50:2190-N50:2219 22191-22220 Auxiliary Analog Input #10 High Shutdown (Zones 1 – 30) 441
22220-22222 N50:2220-N50:2222 22221-22223 Digital Board 1, Port 4 Comm. Shutdown (Zones 1 – 3) 2375
22223-22225 N50:2223-N50:2225 22224-22226 Digital Board 2, Port 4 Comm. Shutdown (Zones 4 – 6) 2376
22226-22228 N50:2226-N50:2228 22227-22229 Digital Board 3, Port 4 Comm. Shutdown (Zones 7 – 9) 2377
22229-22231 N50:2229-N50:2231 22230-22232 Digital Board 4, Port 4 Comm. Shutdown (Zones 10 – 12) 2378
22232-22234 N50:2232-N50:2234 22233-22235 Digital Board 5, Port 4 Comm. Shutdown (Zones 13 – 15) 2379
22235-22237 N50:2235-N50:2237 62236-62238 Digital Board 1, Port 3 Comm. Shutdown (Zones 16 – 18) 2385
22238-22240 N50:2238-N50:2240 62239-62241 Digital Board 2, Port 3 Comm. Shutdown (Zones 19 – 21) 2386
22241-22243 N50:2241-N50:2243 62242-62244 Digital Board 3, Port 3 Comm. Shutdown (Zones 22 – 24) 2387
22244-22246 N50:2244-N50:2246 62245-62247 Digital Board 4, Port 3 Comm. Shutdown (Zones 25 – 27) 2388
22247-22249 N50:2247-N50:2249 62248-62250 Digital Board 5, Port 3 Comm. Shutdown (Zones 28 – 30) 2389
22250-22252 N50:2250-N50:2252 62251-62253 Digital Board 6, Port 4 Comm. Shutdown (Zones 1 – 3) 2380
22253-22255 N50:2253-N50:2255 62254-62256 Digital Board 7, Port 4 Comm. Shutdown (Zones 4 – 6) 2381
22256-22258 N50:2256-N50:2258 62257-62259 Digital Board 8, Port 4 Comm. Shutdown (Zones 7 – 9) 2382
22259-22261 N50:2259-N50:2261 62260-62262 Digital Board 9, Port 4 Comm. Shutdown (Zones 10 – 12) 2383
22262-22264 N50:2262-N50:2264 62263-62265 Digital Board 10, Port 4 Comm. Shutdown (Zones 13 – 15) 2384
22265-22267 N50:2265-N50:2267 62266-62268 Digital Board 6, Port 3 Comm. Shutdown (Zones 16 – 18) 2390
22268-22270 N50:2268-N50:2270 62269-62271 Digital Board 7, Port 3 Comm. Shutdown (Zones 19 – 21) 2391
22271-22273 N50:2271-N50:2273 62272-62274 Digital Board 8, Port 3 Comm. Shutdown (Zones 22 – 24) 2392
22274-22276 N50:2274-N50:2276 62275-62277 Digital Board 9, Port 3 Comm. Shutdown (Zones 25 – 27) 2393
22277-22279 N50:2277-N50:2279 62278-62280 Digital Board 10, Port 3 Comm. Shutdown (Zones 28 – 30) 2394
22280-22282 N50:2280-N50:2282 62281-62283 Analog Board 1, Port 4 Comm. Shutdown (Zones 1 – 3) 2395
22283-22285 N50:2283-N50:2285 62284-62286 Analog Board 2, Port 4 Comm. Shutdown (Zones 4 – 6) 2396
22286-22288 N50:2286-N50:2288 62287-62289 Analog Board 3, Port 4 Comm. Shutdown (Zones 7 – 9) 2397
22289-22291 N50:2289-N50:2291 62290-62292 Analog Board 4, Port 4 Comm. Shutdown (Zones 10 – 12) 2398
22292-22294 N50:2292-N50:2294 62293-62295 Analog Board 5, Port 4 Comm. Shutdown (Zones 13 – 15) 2399
22295-22297 N50:2295-N50:2297 62296-62298 Analog Board 1, Port 3 Comm. Shutdown (Zones 16 – 18) 2400
22298-22300 N50:2298-N50:2300 62299-62301 Analog Board 2, Port 3 Comm. Shutdown (Zones 19 – 21) 2401
