Frick QUANTUM LX - Page 81

QUANTUM
™
LX EVAPORATOR CONTROL PANEL
COMMUNICATIONS SETUP
090.610-CS (MAY 2016)
Page 81
SETPOINT VALUES: (Read/Write)
Frick®
Address
AB
Address
Modbus
Address
Description of Data
Default
Value
Units Min. Max.
38590-38619 N70:8590-N70:8619 78591-78620
Liquid Modulating Valve Maximum
Open Mode 1 (Zones 1 – 30)
100 Percent % 0 100
38620-38649 N70:8620-N70:8649 78621-78650
Liquid Modulating Valve Maximum
Open Mode 2 (Zones 1 – 30)
100 Percent % 0 100
38650-38679 N70:8650-N70:8679 78651-78679
Liquid Modulating Valve Maximum
Open Mode 3 (Zones 1 – 30)
100 Percent % 0 100
38680-38709 N70:8680-N70:8709 78681-78709
Liquid Modulating Valve Maximum
Open Mode 4 (Zones 1 – 30)
100 Percent % 0 100
38740-38769 N70:8740-N70:8769 78741-78770
Fan Cycling On Time Heat Cycle
Mode 1 (Zones 1 – 30)
3 Minutes 0 1,000
38770-38799 N70:8770-N70:8799 78771-78800
Fan Cycling On Time Heat Cycle
Mode 2 (Zones 1 – 30)
3 Minutes 0 1,000
38800-38829 N70:8800-N70:8829 78801-78830
Fan Cycling On Time Heat Cycle
Mode 3 (Zones 1 – 30)
3 Minutes 0 1,000
38830-38859 N70:8830-N70:8859 78831-78860
Fan Cycling On Time Heat Cycle
Mode 4 (Zones 1 – 30)
3 Minutes 0 1,000
38890-38919 N70:8890-N70:8919 78891-78920
Fan Cycling Off Time Heat Cycle
Mode 1 (Zones 1 – 30)
27 Minutes 0 1,000
38920-38949 N70:8920-N70:8949 78921-78950
Fan Cycling Off Time Heat Cycle
Mode 2 (Zones 1 – 30)
27 Minutes 0 1,000
38950-38979 N70:8950-N70:8979 78951-78979
Fan Cycling Off Time Heat Cycle
Mode 3 (Zones 1 – 30)
27 Minutes 0 1,000
38980-39009 N70:8980-N70:9009 78981-79009
Fan Cycling Off Time Heat Cycle
Mode 4 (Zones 1 – 30)
27 Minutes 0 1,000
39040-39069 N70:9040-N70:9069 79041-79070
Liquid Modulating Valve Setpoint
Mode 1 (Zones 1 – 30)
40 Temp. -20 150
39070-39099 N70:9070-N70:9099 79071-79100
Liquid Modulating Valve Setpoint
Mode 2 (Zones 1 – 30)
40 Temp. -20 150
39100-39129 N70:9100-N70:9129 79101-79130
Liquid Modulating Valve Setpoint
Mode 3 (Zones 1 – 30)
40 Temp. -20 150
39130-39159 N70:9130-N70:9159 79131-79160
Liquid Modulating Valve Setpoint
Mode 4 (Zones 1 – 30)
40 Temp. -20 150
39190-39219 N70:9190-N70:9219 79191-79220
Liquid Modulating Valve Propor-
tional Band Mode 1 (Zones 1 – 30)
2
Temp.
(Magnitude)
0 100
39220-39249 N70:9220-N70:9249 79221-79250
Liquid Modulating Valve Propor-
tional Band Mode 2 (Zones 1 – 30)
2
Temp.
(Magnitude)
0 100
39250-39279 N70:9250-N70:9279 79251-79279
Liquid Modulating Valve Propor-
tional Band Mode 3 (Zones 1 – 30)
2
Temp.
(Magnitude)
0 100
39280-39309 N70:9280-N70:9309 79281-79309
Liquid Modulating Valve Propor-
tional Band Mode 4 (Zones 1 – 30)
2
Temp.
(Magnitude)
0 100
39340-39369 N70:9340-N70:9369 79341-79370
Liquid Modulating Valve Integra-
tion Time Mode 1 (Zones 1 – 30)
30 Seconds 0 999
39370-39399 N70:9370-N70:9399 79371-79400
Liquid Modulating Valve Integra-
tion Time Mode 2 (Zones 1 – 30)
30 Seconds 0 999
