Frick QUANTUM LX - Page 9

QUANTUM
™
LX EVAPORATOR CONTROL PANEL
COMMUNICATIONS SETUP
090.610-CS (MAY 2016)
Page 9
ETHERNET COMPONENT RECOMMENDATIONS
Component Description Part Number Manufacturer
Cable
Shielded solid 4-pair* (1000 Ft) BOXCAT5E-DSSO Cablesforless.com
Shielded solid 4-pair*
E-PLG-SOLID-SH VPI
CR45-100S Cables Direct
9504 CS
Alpha Wire Co.
Un-shielded solid 4-pair**
9504 F
E-PLG-SOLID VPI
Un-shielded solid 4-pair** (1000 Ft)
345U5-1000BLK Ram Electronics
0-5EPCS-BK Computercablestore.com
Crimp Tool RJ-45 Crimp tool
HT-210C Cablesforless.com
P-15027 Stonewall Cable, Inc.
S2307692 Computers4sure.com
10-RJ1145 Computercablestore.com
Connectors
RJ-45 For Shielded 4-pair solid wire cable P-15007 Stonewall Cable, Inc.
RJ-45 For Un-shielded 4-pair solid wire cable
5-554169-3 Tyco Electronics
1-5E45-010 Computercablestore.com
P-15029 Stonewall Cable, Inc.
Cable Tester
Ethernet Cable Tester – Continuity only
TST-5150 Cablesforless.com
TS075A-R2 Black Box
Complete Cable I/O Qualication Tester N/A Fluke
Switches
5 RJ-45 port SFN-5TX
Phoenix7 RJ-45 Port and 1 ST Fiber Optic Port SFN-7TX/FX ST
8 RJ-45 port SFN-8TX
* STP = Shielded Twisted Pair
** UTP = Unshielded Twisted Pair
