VYPER
™
VARIABLE SPEED DRIVE
MAINTENANCE
100-210 IOM (JUL 09)
Page 70
PART DESCRIPTION FRICK PART NUMBER
U33 Battery Backed RAM VSD Logic Brd. 639A0214H01
U34 VSD Logic Brd.EPROM 639A0213H02*
U45 VSD Logic Brd. EPROM 639A0213H03*
U26 IEEE-519 Filter Serial Eprom 639A0214H04*
U42 IEEE-519 Filter EPROM 639A0213H05*
U42 IEEE-519 Filter EPROM (50Hz) 639A0213H06*
VSD Logic Board 639A0213H07*
Circuit Breaker 1200 Amp 639A0214H02
Metal Oxide Varistors 639A0213H09*
Input / Output Current Transformers 639A0214H03
Free Wheeling Diode (1CR) 639A0213H11*
SCR Trigger Brd. (60Hz) 639A0213H12*
SCR Trigger Brd. (50Hz) 639A0213H13
Internal Cabinet Fan 639A0211H37**
DC Link Inductor 639A0214H04
Resisitor, Pre-Charge 639A0213H14*
Resistor, DC Balancing 639A0213H16*
Coolant Pump @ Coolant Header 639A0211H30**
Coolant Pump @ Heat Exchager 639A0213H16*
Plate Heat Exchanger 639A0213H17*
Coolant (pre-mixed) 639A0211H36**
Control Transformer 3KVA (60Hz) 639A0211H40**
Control Transformer 3KVA (50Hz) 639A0211H41**
Control Transformer 2KVA (60Hz) 639A0213H19*
Control Transformer 2KVA (50Hz) 639A0213H20*
Transformer 24VAC 639A0211H39**
Relay, Control Fan/Pump 639A0211H34**
15 Amp Cartridge Fuse (5Hp Oil Pump/Blower Supply) 639A0213H22*
20 Amp Cartridge Fuse (7 1/2Hp Oil Pump/Blower Supply) 639A0213H23*
7 Amp Cartridge Fuse 639A0213H24*
10 Amp Cartridge Fuse 649A0213H25*
20 Amp Cartridge Fuse 639A0211H17**
30 Amp Cartridge Fuse 639A0213H27*
Input Fuses, 1600 Amp/700 Volt 639A0214H05
Input SCR Replacement Kit 1, 2, & 3SCR 639A0214H06
Input Diode Replacement Kit (1D, 2D & 3D) 639A0214H07
VSD Output Pole Assembly 639A0214H08
Board, Gate Driver 639A0213H55*
Snubber Resistor, 10 Ohm 639A0213H30*
Positive Bus Plate 639A0213H31*
Negative Bus Plate 639A0213H32*
Insulator Sheet 639A0213H33*
K-1 contactor 639A0213H34*
3-Way Electronic Valve (1" port) Valve Only 639A0213H35*
Electronic Valve Actuator 639A0211H62**
Operator Disconnect Handle (door) 639A0213H36
Fuse Holder 639A0213H37
Contactor, 3-pole, 12amp (Oil Pump) 639A0213H51*
Oil Pump Starter, Overload (5HP) 639A0213H53*
Oil Pump Starter, Overload (7.5HP) 639A0213H54*
Contactor 1M 639A0213H55*
Contactor, 3-pole 9amp (Blower Motor) 639A0211H68**
Blower Motor Starter, Overload 639A0211H70**
Blower Motor Aux. Contact 639A0211H71**
1. Shaded rows are recommended spare parts.
* Also Used On the 700HP Drive
** Also Used On the 305 & 437HP Drives
912 HP SPARE PARTS LIST
