VYPER
™
VARIABLE SPEED DRIVE
INDEX
100-210 IOM (JUL 09)
Page 71
HARMONIC FILTER SPARE PARTS LISTS
1
MODEL 700 PART DESRIPTION FRICK PART #
Filter Logic Board 639A0213H38
Filter Input Fuse, 300 Amp, 500 Volt 639A0213H39
Bus Isolator Board 639A0211H42*
Line Isolator Board 639A0211H44*
Filter Trap Assembly 639A0213H40
3-Phase Filter Inductor 639A0213H41
Filter Input Contactor 639A0213H42
Snubber Capacitor, .047 MFD 639A0213H43
Snubber Resistor, 10 Ohm 639A0213H44
Electronic Current Sensor 1000 amp 639A0213H45
Filter Pre-Charge Contactor 639A0213H46
519’ Filter Pole Assembly 639A0213H47
Resisitor, Filter, Pre-Charge 639A0213H48
Filter Upgrade (60Hz) 639A0213H49
Filter Upgrade (50Hz) 639A0213H50
1. Shaded rows are recommended spare parts.
* Also Used On the 305 & 437HP Drives
MODEL 912 PART DESRIPTION FRICK PART #
Filter Logic Board 639A0214H09
Filter Input Fuse, 500 Amp, 500 Volt 639A0214H10
Bus Isolator Board 639A0211H42**
Line Isolator Board 639A0211H44**
Filter Trap Assembly 639A0214H11
3-Phase Filter Inductor 639A0214H12
Filter Input Contactor 639A0214H13
Snubber Capacitor, .047 MFD 639A0213H43*
Snubber Resistor, 10 Ohm 639A0213H44*
Electronic Current Sensor (2000 Amp) 639A0214H14
Filter Pre-Charge Contactor 639A0213H46*
519’ Filter Pole Assembly 639A0213H15
Resisitor, Filter, Pre-Charge 639A0213H48*
Filter Upgrade/Retrofit Kit (60Hz) 639A0214H16
Filter Upgrade/Retrofit Kit (50Hz) 639A0214H17
1. Shaded rows are recommended spare parts.
* Also Used On the 700HP Drive
** Also Used On the 305 & 437HP Drives
