Preparing Your Installation Site
wireless at the speed of light …………….
11
-Series Installation Manual
Terminal Mounting Options
In order to achieve a reliable and problem-free FSO link, the importance of a rigid and
stable mount for your SONAbeam terminals cannot be overstated.
The design, fabrication and erection of the mounting mast are all tailored to your specific
installation site(s) and these operations are left to the responsible equipment installers.
This section illustrates a variety of mounting ideas along with two, ‘off-the-shelf’
mounting options available from fSONA Networks..
ROOF TOP MOUNTING:
PARAPET OR WALL MOUNTING:
into a mount for –E or --Z
Stones, this quickly
fabricated structure ‘sits’ on
