Installing Your SONAbeam Terminal
wireless at the speed of light ……………. 43
SONAbeam E
-Series Installation Manual
Terminal Management Connections
Your SONAbeam terminal provides three Terminal Management Ports: Serial (RS232),
USB and Ethernet, as shown in Figure 15.
Figure 15 – Completed Customer Interface (with all MGMT connections)
Serial (RS232) Terminal
Management Port
Ethernet (LAN) Terminal
Management Port
USB Terminal
Management Port
