Installing Your SONAbeam Terminal
40
wireless at the speed of light …………….
NAbeam E-Series Installation Manual
SONAbeam Power Connections:
The following table provides a guide to assigning standard power cable wire colours to
associated power terminals:
Type I cable:
Wire Colour
DC Power Connections AC Power Connections
GREEN GROUND GROUND
WHITE 0 V Neutral (Line)
BLACK -48 V Line
Type II cable:
Wire Colour
DC Power Connections AC Power Connections
GREEN-YELLOW GROUND GROUND
BLUE 0 V Neutral (Line)
BROWN -48 V Line
