Fuji Electric Micro-controller X Series User Manual

11
Communication
protocol setting
Re-transmission
output type setting
Re-transmission
output scaling base
side setting
Re-transmission
output scaling span
side setting
Remote SV input
zero adjustment
Remote SV input
span adjustment
Remote SV input
filter constant
Remote SV input
value display
Parameter mask
Switches communication protocols
between Modbus and ASCII
Sets the type of signals to be outputted
from re-transmission output.
Re-transmission output scaling setting
on the base side
Re-transmission output scaling on the
span side
Shifts the zero point of input value.
Shifts the span point of input value.
Sets the filter constant of remote SV
input value.
Displays remote SV input value.
Sets whether or not to display each
parameter.
0 : Z-ASCII
1 : Modbus (RTU)
Setting range
0 : PV / 1 : SV / 2 : MV/ 3 : DV (
* : 0)
Setting range
- 100.0 to 100.0% (* : 0.0)
Setting range
- 100.0 to 100.0% (* : 100.0)
- 50 to 50%FS (*: 0)
- 50 to 50%FS (*: 0)
0.0 to 900.0 seconds (*: 0.0)
-
0 to 255 (*: specified by customer
while ordering)
dP13-2
dP13-4
dP13-4
dP13-4
dP13-16
dP13-16
dP13-16
dP13-16
–
78
72
73
74
74
75
75
76
77
Parameter
display symbol
User’s
set value
Reference
page
Parameter name
Description
Setting range and factory
default setting (*)
Parameter
mask DSP
Note: The parameters for which * is marked with the page number in
Reference page are related to Remedies of “4” on page 79.
