Output offset value (Setting range:
-
100.0 to 100.0 %)
Anti-reset windup (Setting range: 0 to 100%FS)
[Description]
• The anti-reset windup (
) is automatically set to an
optimum value by the auto-tuning operation.
By setting , the amount of overshoot can be adjusted.
[Note]
By making use of the fuzzy control system equipped with
PXR, the amount of overshoot can be minimized without
setting and .
[Setting example] Changing the anti-reset windup from 60˚C to 80˚C.
Press and hold the
SEL
key for three seconds.
will be displayed on the PV display.
Press the
key to display
.
Press the
SEL
key once.
The current setting (
) flashes on the SV display.
Press the or keys to display .
Press the
SEL
key once. will stop flashing and will be registered for . After that, the
controller will operate with the anti-reset windup being 80˚C.
If you want to display the operation status, press and hold the
SEL
key for two seconds.
Operating procedureDisplay
1.
2.
3.
4.
5.
PV
SV
}
}
}
AR value
AR value
In this range, the integral
operation is not performed.
In this range, the integral
operation is performed.
In this range, the integral
operation is not performed.
6.
To Next Page
