How to set values:
key: One press increases the value by 1.
Press and hold this key to increase the value fast.
key: One press decreases the value by 1.
Press and hold this key to decrease the value fast.
How to register the set data:
By pressing the
SEL
key, the displayed values are registered.
Note that the SV (SV0) will be registered in 3 seconds without any operation.
C1 C2 AL1 AL2 AL3
PV
SV
°C
PXR
SEL
Just after power-on
(PV/MV displayed)
C1 C2 AL1 AL2 AL3
PV
SV
°C
PXR
SEL
(PV/SV displayed)
SEL SEL
SEL
(approx.
1 second)
Changes MV.
Not operated
for 30 seconds.
(approx.
3 seconds)
(approx.
5 seconds)
Parameters of the
first block
Parameters of the
second block
Parameters of the
third block
SEL
SEL
Changes SV.
Basic operations for the PXR (In Manual mode)
PV
SV
PV
SV
PV
SV
PV
SV
SEL
SEL
Setting parameters
Pressing and holding the
keys makes the value increase or
decrease fast.
