Machine Components
67
Product Overview
2
Note • In this guide, the duplex automatic document feeder is referred to as the "document feeder" or
"DADF".
îš„ Tandem Tray Module Model
5 Document feeder tray Load documents here.
6 Document output tray Scanned documents are delivered here.
7 Document stopper Prevents outputs from falling off.
8 Side 2 constant velocity
transport glass
Scans Side 2 of the loaded document.
9 Side 1 constant velocity
transport glass
Scans Side 1 of the loaded document.
No. Component Function
1
2
No. Component Function
1 Tray 3 (optional) Load paper here.
2 Tray 4 (optional) Load paper here.
