Activity Report
873
Appendix
16
Start Time The date and time that the communication began are shown. In Batch
Send, the start time of the transmission for each document is recorded.
Duration The duration of the transmission is displayed. In Batch Send, it is the
length of time taken to transmit each document is recorded.
Pages "-" is shown when the number of pages is 0.
z
Transmitting
The number printed on the left side of the slash "/" indicates the number
of pages that were successfully transmitted. The number printed on the
right side of the slash "/" indicates the number of total pages. In Batch
Send, the number of total pages is not shown.
z
Receiving/Polling
The number of pages that the machine successfully received is shown.
z
Depending on the transmission status on the recipient's machine or the setting
of the machine, the value in [Pages] may differ from the actual number of
pages printed.
Mode The mode used for the communication is shown.
There are three modes: G3, EC, and SG3 (Super G3). (This field is blank if a
mode other than above these was used.)
When IP Fax (SIP) is used:
IP Fax or IP Fax-ECM
Contents The information about the communication is indicated. See the Note field
at the bottom of the report for a list of abbreviations and their definitions.
z
Transmitting
1 Remote service
2 Redial
3 Folder XXX
4 Broadcast/Multi-Poll
5 Polling
6 Relay Broadcast Assignment
7 Fax forwarding box XXX
When IP Fax (SIP) is used:
1 Redial
2 Folder XXX
3 Broadcast/Multi-Poll
4 Polling
z
Receiving
1 Folder XXX
2 Polling
3 Receiving line box XXX
When IP Fax (SIP) is used:
1 Folder XXX
2 Polling
3 Receiving line box XXX
z
XXX indicates the Folder number.
Status The result of the operation is indicated.
Completed : The operation ended normally.
Busy : The recipient is busy or did not answer.
Auto Send : The document is being re-sent and the set re-send
times has not been exceeded.
Canceled : The communication was terminated.
Item Description
To Next Page
