5 Maintenance
100
Maintenance
5
Replacing Booklet Staple Cartridge (for C3 Finisher with Booklet Maker)
When the C3 Finisher with Booklet Maker (optional) is installed and the booklet staple
cartridges need to be replaced, a message appears on the touch screen. When this message
appears, replace the booklet staple cartridges with new ones.
* : The messages above are for the Booklet Staple Cartridge [R2]. For the Booklet Staple Cartridge [R3], [R3] is displayed.
Important • The use of booklet staple cartridges not recommended by Fuji Xerox may degrade quality and
performance. Use only booklet staple cartridges recommended by Fuji Xerox.
• When the machine is in Power Saver mode, exit Power Saver mode by pressing the <Power Server>
button on the control panel before you replace the staple cartridge.
• When replacing the staple cartridge, press the <Machine Status> button and check the current
status for the staple cartridge even when the control panel is lit.
Note • If the booklet staple cartridge was not replaced properly, the message remains on the touch screen.
Follow the procedure and replace the booklet staple cartridge again.
• To order a booklet staple cartridge, contact our Customer Support Center.
1
Make sure that the machine is not operating,
and open the finisher front door.
2
Pull out the booklet unit.
3
With grasping the lever of the booklet staple
cartridge, push the booklet staple cartridge
downward. Then, pull out the booklet staple
cartridge upward.
Message Solution
The Booklet Staple cartridge [R2] is running out
of staples. Please order a Booklet Staple
Cartridge [R2].
Prepare new staples.
Note • Staples cannot be replaced yet.
The Booklet Staple Cartridge [R2] is out of
staples or not fully inserted. Check the Staple
Cartridge [R2].
Replace staples with new ones.
To Next Page
