Control Panel
47
Product Overview
2
Control Panel
The following describes the names and functions of components on the control panel.
No. Component Function
1 <Services Home> button Press this button to display the Services Home screen.
You can change the services displayed on the Services Home screen.
2 Touch screen Displays messages required for operation, and buttons for various features.
You can directly touch the touch screen to instruct operations and set
features.
3 <Log In/Out> button Lights up when a user is authenticated in the System Administration mode,
the Authentication mode, or the Accounting mode. Displays the User ID
entry screen for entering the System Administration mode, the
Authentication mode, or the Accounting mode. Press this button to exit
these modes.
4 <Job Status> button Press this button to check or cancel the current job, to check or print stored
jobs, or to check completed jobs.
5 <Machine Status> button Press this button to check the machine status and meters, to check the
status of consumables, and to print reports.
6
<P
ower Saver>
button
When the machine is not used for a while, it enters the Power Saver mode to
reduce power consumption. When the Power Saver mode is active, the
<Power Saver> button lights up.
Press this button to enter or exit the Power Saver mode.
7 Push-button power switch Switches the power of the machine on and off.
8 <Interrupt> button Press this button to suspend a copy or print job in progress to have the
machine process another job. During the Interrupt mode, the <Interrupt>
button lights up. Pressing the <Interrupt> button again exits the Interrupt
mode and resumes the suspended job.
9 <Clear All> button Returns the settings you made to the default values. The machine returns to
the same state as when it is powered on.
123
456
789
0
＃
C
123
456
789
0
＃
C
1213141516171819202122232425
26
10
11
9
8
12 34567
