Replacing the Staple Cartridge
99
Maintenance
5
Replacing Booklet Staple Cartridge (for Booklet Maker Unit for Finisher B1)
When the Booklet Maker Unit for Finisher B1 (optional) is installed and the booklet staple
cartridges need to be replaced, a message appears on the touch screen. When this message
appears, replace the booklet staple cartridges with new ones.
Important • The use of booklet staple cartridges not recommended by Fuji Xerox may degrade quality and
performance. Use only booklet staple cartridges recommended by Fuji Xerox.
• When the machine is in the Power Saver mode, exit the Power Saver mode by pressing the <Power
Saver> button on the control panel before you replace the staple cartridge.
• When replacing the staple cartridge, press the <Machine Status> button and check the current
status for the staple cartridge even when the control panel is lit.
Note • To order a staple cartridge, contact our Customer Support Center.
1
Make sure that the machine is not operating,
and open the finisher side cover.
2
Hold the tabs on both sides of the staple
cartridge and pull the cartridge out of the
finisher.
3
Hold the tabs on both sides of a new staple
cartridge, and insert it into the original position
until it clicks.
4
Repeat steps 2 and 3 to replace the other staple cartridge.
5
Close the finisher side cover.
Note • If the cover is not completely closed, a message will appear and the machine remains paused.
