Stapler Faults
143
Troubleshooting
6
Staple Jams in Staple Cartridge (for Finisher A2)
This section describes how to clear staple jam occurred in the staple cartridge of the Finisher
A2 (optional).
1
Make sure that the machine is not operating,
and gently open the finisher front cover.
2
Take the staple cartridge out of the machine.
Note • The staple cartridge is firmly inserted. A slight
force is required to pull the cartridge out of
the finisher.
3
After you take out the staple cartridge, check
inside of the finisher for any remaining staples.
Remove any staples remaining inside.
4
Pull up the metal part of the staple cartridge as
shown in the illustration.
5
Remove the jammed staples (1), and then
return the metal part pulled up in step 4 to the
original position (2).
Be careful in removing jammed staples.
To Next Page
