2 Product Overview
46
Product Overview
2
Note • The C3 Finisher and the C3 Finisher with Booklet Maker are optional. The common features of the
Finisher A2, Finisher B1, and C3 Finisher described in this guide are referred to as the "finisher".
9 Booklet staple cartridge Two staple cartridges for booklet creation. Take out the cartridges when
clearing stapled jams, or when replacing them with new ones.
10 Tri-fold output tray
(When the optional Folder
Unit CD1 is installed)
Tri-folded outputs are delivered here.
11 Folder Unit cover
(When the optional Folder
Unit CD1 is installed)
Open this cover to clear paper jams.
12 Finisher transport center tray
(Top cover of the finisher
transport)
Copies and prints are delivered here when they are unable to be delivered to
the output tray or finisher tray. Pull the cover upward when clearing paper
jams.
Note •Remove outputs delivered to the center tray constantly.
No. Component Function
To Next Page
