6 Troubleshooting
148
Troubleshooting
6
2
Pull out the booklet unit.
3
With grasping the lever of the booklet staple
cartridge, push the booklet staple cartridge
downward. Then, pull out the booklet staple
cartridge upward.
4
Push down the metal part of the staple
cartridge.
5
Remove the jammed staples (1), and return the
metal part pushed down in step 4 to its original
position (2).
6
Return the booklet staple cartridge to its
original position.
Be careful in removing jammed staples.
To Next Page
