Technical data
Ports
Monitor port (analogue) 15-pin socket
LAN port Socket, RJ45
Modem connection (optional) connector, RJ11
Microphone port/ line In 3.5 mm stereo mini jack
Headphones port/Line Out 3.5 mm stereo mini jack
Docking port 80-pin
USB (Universal Serial Bus) 3 x USB 2.0
Infrared interface Fast IrDa 1.1
Kensington Lock 2 x
Environmental conditions
Environment class DIN IEC 721 7K1
Mechanism class DIN IEC 721 7M2
Temperature:
Operation 5°C .... 35°C
Transport (2K2) –15°C .... 60°C
Port Replicator (optional)
Electrical data
Regulations complied with CE
Protection class II
Ports
Monitor port (analogue) 15-pin socket
Monitor port (digital) 25-pin female connector, DVI-D
LAN port Socket, RJ45
USB (Universal Serial Bus) 4x USB 2.0
Audio Line out
Docking port 80-pin
Environmental conditions
Environment class DIN IEC 721 7K1
Mechanism class DIN IEC 721 7M2
Temperature
Operation 5°C .... 35°C
Transport –15°C .... 60°C
102 A26391-K220-Z122-1-7619, edition 1
