Fujitsu D2924 User Manual

Advanced Menu – Advanced system confi
guration
Advanced System Configuration
Systemsettings, additional
Advanced System Configuration
Item Specific Help
Primary Display: [Auto]
IGD - Device 2:
[Auto]
Select ’IGD’ to have
Internal Graphics,
if supported and
enabled, be used
for the boot
display device.
Select ’PEG’ to have
PCI Express Graphics,
if supported and
enabled, be used
for the boot display
device.
High Precision Event Timer:
[Enabled]
SMART Device Monitoring:
[Enabled]
SATA Mode Selection:
[AHCI]
SATA Port 0:
[Internal]
[Internal]
[Internal]
[Internal]
IGD - Memory Size:
Pre - Allocated Memory Size:
[32M]
[MaxDVMT]
SATA Port 1:
SATA Port 2:
SATA Port 3:
SATA Port 4:
[Internal]
SATA Port 5:
[Internal]
Auto
Enabled
Example showing
the Advanced System Configuration menu
Opens the subme
nu used to make additio nal system settings.
Display, primary
Display,primary
Specifies the picture source during the BIOS POST.
IGD
The Integrated Graphics Device (IGD) on the system board is used as the picture
source during the BIOS POST.
PEG
If it is inserted, the PCI Express graphics card serves as the picture source during
the BIOS POST.
PCI
If it is inserted, the PCI graphics card serves as th e picture source during the BIOS
POST.
Auto
The first available picture source in the sequence PEG, PCI or IGD is used as the
picture source during the BIOS POST.
IGD – Device 2
Specifies whether the Integrated Graphics Device (IGD) is available.
Disabled
The In
tegrated Graphics Device is not available.
Auto
The Integrated Graphics Device is available. Use of the d evice depends on the
settings under "Primary Display" and any additional graphics card which may be
inserted.
Fujitsu Technology Solutions 23
