Security
Menu
-
Security
features
►
Insert
the
next
SmartC
ard
and
initialise
this
as
required.
The
following
prom
pt
will
be
displayed:
Remove
the
SmartCar
d.
Always
change
the
PIN
and
PUK
for
each
additional
SmartCard.
The
PUK
is
used
to
reactivate
a
blocked
SmartCard
v
ia
the
Unblock
SmartCard
function.
►
Remove
the
user
SmartCard
and
label
it,
e.g.
with
the
name
of
the
user
.
Never
write
the
PIN
on
the
SmartCard!
52
Fujitsu
T
echnology
Solutions
55
57
Table of Contents
Table of Contents
7
Introduction
11
Notational Conventions
12
Navigating BIOS Setup
13
Open BIOS Setup
13
If You Want to Open the "Boot Menu" Immediately
13
BIOS Setup with Incorrect Settings
14
Navigating BIOS Setup
15
Exiting BIOS Setup
15
Main Menu - System Functions
16
System Date/System Time
16
Diskette a - Floppy Disk Drive
16
SATA Port
17
Total Sectors
17
Maximum Capacity- Hard Disk Capacity
18
Multi-Sector Transfers
18
LBA Mode Control
19
32 Bit I/O - Bus Width for Data Transfer
19
Transfer Mode
19
Ultra DMA Mode - Transfer Speed
19
SMART Monitoring
19
Firmware
20
Silent Mode - Noise Level for Hard Disks and Optical Drive
20
Password Status - Display Hard Disk Password Status
20
Change Password
20
Hard Disk Master Password
20
Hd-ID
21
Boot Features - System Boot
21
POST Errors - Aborting System Boot
21
SM Error Halt
21
Fast Boot - Quick Self-Test
21
POST Diagnostic Screen - POST Information or Boot Logo
22
Boot Menu - System Boot
22
System Memory - Working Memory
22
Extended Memory/Memory Speed
22
Advanced Menu - Advanced System Configuration
23
Peripheral Configuration - Ports and Controllers
24
Serial 1/Serial 2 - Serial Ports
24
Parallel Port (System-Dependent)
24
Floppy Disk Controller
25
USB Host Controller
25
USB BIOS Hot-Plug
25
Audio Controller
26
Beep Volume
26
LAN/LAN 0 Remote Boot - Load Operating System Via LAN
26
Advanced System Configuration
27
Display, Primary
27
IGD - Device 2
27
Pre-Allocated Memory Size - Fixed Graphics Memory at Boot Time
28
IGD Memory Size
28
High Precision Event Timer
28
SMART Device Monitoring
28
Fan Control - Fan Speed
28
SATA Mode Selection
29
SATA Port 0
29
Advanced Processor Options
29
Enhanced Speedstep
30
Turbo Boost Technology
30
Enhanced Idle Power State
30
Frequency Ratio
30
Virtualization Technology (VT-X)
31
Virtualization Technology (Intel VT-D)
31
NX Memory Protection
31
Adjacent Cache Line Prefetch
31
Hardware Prefetch
31
Hyper-Threading
32
Limit CPUID Functions
32
Core Multi-Processing
32
CPU MC Status Clear
32
CPU Timeout Counter
33
PCI Configuration
34
DMI Event Logging
35
Event Log Validity
35
Event Log Capacity
35
View DMI Event Log
35
Event Logging
35
Mark DMI Events as Read
35
Clear All DMI Event Logs
36
LCD Configuration
36
LCD Time
36
LCD Date
36
LCD BIOS Version
37
LCD LAN MAC Address
37
LCD Product Name
37
LCD Board Serial Number
37
LCD Custom Serial Number
37
LCD Custom String
37
LCD Manufacturer
37
System Management
38
Battery State
38
SM Fan Control
38
Fan State
39
Thermal Sensor State
39
ASF Configuration
39
Minimum Watchdog Timeout
39
BIOS Boot Timeout
39
OS Boot Timeout
39
Power-On Wait Time
40
AMT Sub-Menu
40
ME Firmware Status
40
Platform Manageability
40
ME FW Version
40
Amt Sku
40
Amt Ide-R
41
Amt Sol
41
On-Board Gbe LAN
41
Host MAC Address
41
Dedicated MAC Address
41
Com Port Address
42
Continue C.R. after POST
42
Security Menu - Security Features
43
Assigning and Cancelling Passwords
43
Supervisor Password
43
User Password
43
Set Supervisor Password
44
Password: Setup Password Lock
44
Set User Password
44
Password on Boot
44
Setup Password Lock
44
Set Supervisor / User Password
45
Cancelling Supervisor/User Password
46
Supervisor Password Lock
46
Smartcard Systemlock/Systemlock 2 (Optional)
47
Access Rights for the Smartcard
48
Smartcard User Groups
49
Installing Systemlock
50
Systemlock
50
Adding Systems to a User Group
53
Carrying out Administrator Functions
55
Remote Access Enable
57
Switching on the PC with Systemlock
58
Change PIN
58
Uninstall Systemlock
58
Error Messages
59
TPM (Security Chip) Setting
59
Security Chip
59
Current TPM State
60
TPM Physical Presence Operations
60
Virus Warning
60
ATA Vulnerability Protection
61
Diskette Write - Write Protection for Floppy Disk Drive
61
Flash Write - System BIOS Write Protection
61
Cabinet Monitoring - Protection after Opening the Case
61
Power Menu - Energy Saving Functions
62
Power on Source - Management of Switch-On Sources
62
Power on Source: LAN - Switch on Via LAN Controller
62
Power on Source: Wake up Timer - Switch on According to Time
63
Power Failure Recovery - System Status after a Power Failure
63
Low Power Soft off
64
USB at Power off
64
USB Keyboard
64
Boot Menu - System Boot
65
Boot Priority Order
65
Excluded from Boot Order
65
Exit Menu - Exit BIOS Setup
66
Save Changes & Exit
66
Discard Changes & Exit
66
Get Default Values - Restoring Standard (Default) Settings
66
Load Previous Values - Restoring Previous Settings
66
BIOS Update of USB Stick or Diskette
67
Error Message after a BIOS Update
69
Flash Memory Recovery Mode
69
BIOS Update under Windows with Deskflash Program
70
