Table B-5
Crossbar cable correspondence table
Connection
order
Connector 1 Connector 2 Remarks
1 BB00-XBU1-0L (pink) BB01-XBU1-0L (pink) BB#00 - BB#01
BB00-XBU1-0L (black) BB01-XBU1-0L (black)
BB00-XBU1-0R (light blue) BB01-XBU1-0R (light blue)
BB00-XBU1-0R (black) BB01-XBU1-0R (black)
2 BB02-XBU1-0L (pink) BB03-XBU1-0L (pink) BB#02 - BB#03
BB02-XBU1-0L (black) BB03-XBU1-0L (black)
BB02-XBU1-0R (light blue) BB03-XBU1-0R (light blue)
BB02-XBU1-0R (black) BB03-XBU1-0R (black)
3 BB00-XBU1-1L (pink) BB02-XBU1-1L (pink) BB#00 - BB#02
BB00-XBU1-1L (black) BB02-XBU1-1L (black)
BB00-XBU1-1R (light blue) BB02-XBU1-1R (light blue)
BB00-XBU1-1R (black) BB02-XBU1-1R (black)
4 BB01-XBU1-1L (pink) BB03-XBU1-1L (pink) BB#01 - BB#03
BB01-XBU1-1L (black) BB03-XBU1-1L (black)
BB01-XBU1-1R (light blue) BB03-XBU1-1R (light blue)
BB01-XBU1-1R (black) BB03-XBU1-1R (black)
5 BB00-XBU1-2L (pink) BB03-XBU1-2L (pink) BB#00 - BB#03
BB00-XBU1-2L (black) BB03-XBU1-2L (black)
BB00-XBU1-2R (light blue) BB03-XBU1-2R (light blue)
BB00-XBU1-2R (black) BB03-XBU1-2R (black)
6 BB01-XBU1-2L (pink) BB02-XBU1-2L (pink) BB#01 - BB#02
BB01-XBU1-2L (black) BB02-XBU1-2L (black)
BB01-XBU1-2R (light blue) BB02-XBU1-2R (light blue)
BB01-XBU1-2R (black) BB02-XBU1-2R (black)
7 BB00-XBU0-0L (pink) BB01-XBU0-0L (pink) BB#00 - BB#01
BB00-XBU0-0L (black) BB01-XBU0-0L (black)
BB00-XBU0-0R (light blue) BB01-XBU0-0R (light blue)
BB00-XBU0-0R (black) BB01-XBU0-0R (black)
8 BB02-XBU0-0L (pink) BB03-XBU0-0L (pink) BB#02 - BB#03
BB02-XBU0-0L (black) BB03-XBU0-0L (black)
BB02-XBU0-0R (light blue) BB03-XBU0-0R (light blue)
BB02-XBU0-0R (black) BB03-XBU0-0R (black)
9 BB00-XBU0-1L (pink) BB02-XBU0-1L (pink) BB#00 - BB#02
BB00-XBU0-1L (black) BB02-XBU0-1L (black)
