Fujitsu M10 - Chapter 3 Installing the System; 3.1 Preparing the Necessary Tools;Information for Installation

Table 3-1
List of necessary tools
Name Use
Phillips screwdriver (#2) Used to attach cable support brackets and mount
optional components
Phillips screwdriver (#3) Used to connect racks and attach rails to the rack
supporting columns
Wrench or box wrench (M8 screws securing rack
package: nominal size 13)
Used to unpack an ordinary rack package
Wrench or box wrench (M10 screws securing rack
package: nominal size 17)
Used to unpack an ordinary rack package
Allen wrench (M12 screws securing top cover: nominal
size 8)
Used to connect racks
Chapter 3
Installing the System
This chapter describes the work of preparing for installation, mounting a chassis in a
rack, and mounting optional components.
■
Preparing the Necessary Tools/Information for Installation
■
Confirming Delivered Components
■
Installing a Rack
■
Mounting the Chassis in a Rack
■
Mounting Optional Components
3.1 Preparing the Necessary Tools/
Information for Installation
This section describes the tools and information that are required in installation.
Have these prepared before starting installation work.
67
