No. Port Number on board
3SAS port 1
4 Serial port 1
5XSCF USB port (for field engineers) 1
6XSCF-LAN port 2
8XSCF DUAL control port (*1) 1
9XSCF BB control port (*1) 3
*1 The SPARC M10-4 does not have this port.
2.10.1 Network configuration example
Figure 2-32 shows a network configuration example. For details on network
connections, see "1.3 Network Configuration" in the Fujitsu M10/SPARC M10
Systems System Operation and Administration Guide.
