Fujitsu M10 User Manual

Table 2-19
Power cords and connector shape (PDU of an expansion rack)
Destination Pow er cord type Connector shape
Common For 200 V power supply (*1)
- For single-phase power supply
connection
IEC60309 60A 2P+E
- For three-phase delta connection
IEC60309 60A 3P+E
- For three-phase star connection
IEC60309 30A 3P+N+E
IEC60309 32A 3P+N+E
IEC60320-C20
*1 The following two types of power cords are necessary for each chassis mounted in an expansion rack: 0.5 m
(1.6 ft.) and 1.5 m (4.9 ft.) power cords. The customer needs to order these power cords for each chassis.
Note -
For chassis with plugs that have a lock function, confirm that the chassis have a 15 A
(20 A for the SPARC M10-4/M10-4S) overcurrent protection device. If they do not have that
device, provide 15 A (20 A for SPARC M10-4/M10-4S) overcurrent protection using a circuit
breaker or fuse. The
plugs with a lock function are the NEMA L6-20, L6-15, and other plugs
that are not parallel two-pole connectors with grounding electrodes.
Table 2-20
Distribution panel breaker capacity on the equipment side
Device name Power supply input Distribution panel breaker capacity on
equipment side
For Japan/North
America/other countries
For Europe
SPARC M10-4S Single-phase 200 to 240 VAC 20 A16 A
SPARC M10-4 Single-phase 200 to 240 VAC 20 A16 A
SPARC M10-1 Single-phase 100 to 120 VAC 12 A-
Single-phase 200 to 240 VAC 10 A10 A
Expansion rack Single-phase 200 to 240 VAC 40 A40 A
Expansion rack Three-phase (delta) 200 to
240 VAC
35 A35 A
Expansion rack Three-phase (star) 380 to 415
VAC
24 A24 A
2.9.3 Breaker characteristics
The breaker characteristics for the SPARC M10 systems must be taken into
consideration to allow the devices to be used under the right conditions. Use circuit
breakers that meet the following special conditions for the distribution panel
breakers on the equipment side.
Table 2-20 lists the distribution panel breaker capacity on
the equipment side.
Fujitsu M10/SPARC M10 Systems Installation Guide
･
July 201560
