700 mm
(27.6 in.)
800 mm
(31.5 in.)
1050 mm
(41.3 in.)
900 mm
(35.4 in.)
Rear service area
Rack
(*1)
(*1)
Front service area
(*1)
*1
To
mount
a
chassis
on
the
rack,
an
area
with
a
depth
of
1,200
mm
(47.2
in.)
is
required
in
front
of
the
rack,
and
areas
with
a
width
of
600
mm
(23.6
in.)
are
required
on
both
the
left
and
right
sides
of
the
front
service
area.
If
there
is
a
possibility
that
a
chassis
will
be
added
later,
secure
an
area
with
a
depth
of
1,200
mm
(47.2
in.)
in
front
of
the
rack
and
areas
with
a
width
of
600
mm
(23.6
in.)
on
both
the
left
and
right
sides
of
the
front
service
area.
Figure
2-8
　　
Example
of
service
areas
for
the
PCI
expansion
unit
(top
view)
2.4.3 Mounting
conditions
for
expansion
racks
Building
block
configuration
(connections
through
the
crossbar
boxes
of
the
SPARC
M10-4S)
Dedicated
power
distribution
unit
(PDUs),
crossbar
boxes
(XBBOXs),
and
crossbar
cables
are
shipped
mounted
in
a
dedicated
rack
(expansion
rack).
Figure
2-9
and
Figure
2-10
show
the
chassis
mounting
locations
and
cage
nut
locations,
respectively.
Chapter
2
　
Planning
and
Preparing
for
System
Installation 31
