Fujitsu M10 - Page 78

No. Port Number on board
1, 7USB port 2
2GbE LAN port 4
3SAS port 1
4Serial port 1
5XSCF USB port (for field engineers) 1
6XSCF-LAN port 2
䋨䋹䋩
䋨䋸䋩
䋨䋷䋩
No. Port Number on board
1, 7USB port 2
2GbE LAN port 4
Figure 2-31
Locations of the ports for network connections (SPARC M10-4/M10-4S)
Fujitsu M10/SPARC M10 Systems Installation Guide
･
