Table B-7
Crossbar cable correspondence table (0 system) (continued)
Connected chassis SPARC M10-4S side Crossbar box side
BB04-XBU0-0R (light blue) XB80-XBU0-R4 (light blue)
BB04-XBU0-0R (black) XB80-XBU0-R4 (black)
BB04-XBU0-1L (pink) XB80-XBU1-L4 (pink)
BB04-XBU0-1L (black) XB80-XBU1-L4 (black)
BB04-XBU0-1R (light blue) XB80-XBU1-R4 (light blue)
BB04-XBU0-1R (black) XB80-XBU1-R4 (black)
BB#05 - XBBOX#80 BB05-XBU0-0L (pink) XB80-XBU0-L5 (pink)
BB05-XBU0-0L (black) XB80-XBU0-L5 (black)
BB05-XBU0-0R (light blue) XB80-XBU0-R5 (light blue)
BB05-XBU0-0R (black) XB80-XBU0-R5 (black)
BB05-XBU0-1L (pink) XB80-XBU1-L5 (pink)
BB05-XBU0-1L (black) XB80-XBU1-L5 (black)
BB05-XBU0-1R (light blue) XB80-XBU1-R5 (light blue)
BB05-XBU0-1R (black) XB80-XBU1-R5 (black)
BB#06 - XBBOX#80 BB06-XBU0-0L (pink) XB80-XBU0-L6 (pink)
BB06-XBU0-0L
(black) XB80-XBU0-L6 (black)
BB06-XBU0-0R (light blue) XB80-XBU0-R6 (light blue)
BB06-XBU0-0R (black) XB80-XBU0-R6 (black)
BB06-XBU0-1L (pink) XB80-XBU1-L6 (pink)
BB06-XBU0-1L (black) XB80-XBU1-L6 (black)
BB06-XBU0-1R (light blue) XB80-XBU1-R6 (light blue)
BB06-XBU0-1R (black) XB80-XBU1-R6 (black)
BB#07 - XBBOX#80 BB07-XBU0-0L (pink) XB80-XBU0-L7 (pink)
BB07-XBU0-0L (black) XB80-XBU0-L7 (black)
BB07-XBU0-0R (light blue) XB80-XBU0-R7 (light blue)
BB07-XBU0-0R (black) XB80-XBU0-R7 (black)
BB07-XBU0-1L (pink) XB80-XBU1-L7 (pink)
BB07-XBU0-1L (black) XB80-XBU1-L7 (black)
BB07-XBU0-1R (light blue) XB80-XBU1-R7 (light blue)
BB07-XBU0-1R (black) XB80-XBU1-R7 (black)
Fujitsu M10/SPARC M10 Systems Installation Guide
･
July 2015334
