Note -
The colored areas in the diagram indicate the cables that pass between the racks. See
the correspondence tables in Table B-13 and Table B-14.
Table B-9
Crossbar cable correspondence table (0 system of the expansion rack 1)
Connected chassis SPARC M10-4S side Crossbar box side
BB#00 - XBBOX#80 BB00-XBU0-0L (pink) XB80-XBU0-L0 (pink)
BB00-XBU0-0L (black) XB80-XBU0-L0 (black)
BB00-XBU0-0R (light blue) XB80-XBU0-R0 (light blue)
BB00-XBU0-0R (black) XB80-XBU0-R0 (black)
BB00-XBU0-1L (pink) XB80-XBU1-L0 (pink)
BB00-XBU0-1L (black) XB80-XBU1-L0 (black)
BB00-XBU0-1R (light blue) XB80-XBU1-R0 (light blue)
BB00-XBU0-1R (black) XB80-XBU1-R0 (black)
BB#01 - XBBOX#80 BB01-XBU0-0L (pink) XB80-XBU0-L1 (pink)
BB01-XBU0-0L (black) XB80-XBU0-L1 (black)
BB01-XBU0-0R (light blue) XB80-XBU0-R1 (light blue)
BB01-XBU0-0R (black) XB80-XBU0-R1 (black)
BB01-XBU0-1L (pink) XB80-XBU1-L1 (pink)
BB01-XBU0-1L (black) XB80-XBU1-L1 (black)
BB01-XBU0-1R (light blue) XB80-XBU1-R1 (light blue)
BB01-XBU0-1R
(black) XB80-XBU1-R1 (black)
BB#02 - XBBOX#80 BB02-XBU0-0L (pink) XB80-XBU0-L2 (pink)
BB02-XBU0-0L (black) XB80-XBU0-L2 (black)
BB02-XBU0-0R (light blue) XB80-XBU0-R2 (light blue)
BB02-XBU0-0R (black) XB80-XBU0-R2 (black)
BB02-XBU0-1L (pink) XB80-XBU1-L2 (pink)
BB02-XBU0-1L (black) XB80-XBU1-L2 (black)
BB02-XBU0-1R (light blue) XB80-XBU1-R2 (light blue)
BB02-XBU0-1R (black) XB80-XBU1-R2 (black)
BB#03 - XBBOX#80 BB03-XBU0-0L (pink) XB80-XBU0-L3 (pink)
BB03-XBU0-0L (black) XB80-XBU0-L3 (black)
BB03-XBU0-0R (light blue) XB80-XBU0-R3 (light blue)
BB03-XBU0-0R (black) XB80-XBU0-R3 (black)
BB03-XBU0-1L (pink) XB80-XBU1-L3 (pink)
BB03-XBU0-1L (black) XB80-XBU1-L3 (black)
BB03-XBU0-1R (light blue) XB80-XBU1-R3 (light
blue)
