Note -
The colored areas in the diagram indicate the cables that pass between the racks. See
the correspondence tables in Table B-13 and Table B-14.
Table B-11
Crossbar cable correspondence table (0 system of the expansion rack 2)
Connected chassis SPARC M10-4S side Crossbar box side
BB#08 - XBBOX#82 BB08-XBU0-0L (pink) XB82-XBU0-L0 (pink)
BB08-XBU0-0L (black) XB82-XBU0-L0 (black)
BB08-XBU0-0R (light blue) XB82-XBU0-R0 (light blue)
BB08-XBU0-0R (black) XB82-XBU0-R0 (black)
BB#09 - XBBOX#82 BB09-XBU0-0L (pink) XB82-XBU0-L1 (pink)
BB09-XBU0-0L (black) XB82-XBU0-L1 (black)
BB09-XBU0-0R (light blue) XB82-XBU0-R1 (light blue)
BB09-XBU0-0R (black) XB82-XBU0-R1 (black)
BB#10 - XBBOX#82 BB10-XBU0-0L (pink) XB82-XBU0-L2 (pink)
BB10-XBU0-0L (black) XB82-XBU0-L2 (black)
BB10-XBU0-0R (light blue) XB82-XBU0-R2 (light blue)
BB10-XBU0-0R (black) XB82-XBU0-R2 (black)
BB#11 - XBBOX#82 BB11-XBU0-0L (pink) XB82-XBU0-L3 (pink)
BB11-XBU0-0L (black) XB82-XBU0-L3 (black)
BB11-XBU0-0R (light
blue) XB82-XBU0-R3 (light blue)
BB11-XBU0-0R (black) XB82-XBU0-R3 (black)
BB#12 - XBBOX#82 BB12-XBU0-0L (pink) XB82-XBU0-L4 (pink)
BB12-XBU0-0L (black) XB82-XBU0-L4 (black)
BB12-XBU0-0R (light blue) XB82-XBU0-R4 (light blue)
BB12-XBU0-0R (black) XB82-XBU0-R4 (black)
BB12-XBU0-1L (pink) XB82-XBU1-L4 (pink)
BB12-XBU0-1L (black) XB82-XBU1-L4 (black)
BB12-XBU0-1R (light blue) XB82-XBU1-R4 (light blue)
BB12-XBU0-1R (black) XB82-XBU1-R4 (black)
BB12-XBU0-2L (pink) XB82-XBU2-L4 (pink)
BB12-XBU0-2L (black) XB82-XBU2-L4 (black)
BB12-XBU0-2R (light blue) XB82-XBU2-R4 (light blue)
BB12-XBU0-2R (black) XB82-XBU2-R4 (black)
BB#13 - XBBOX#82 BB13-XBU0-0L (pink) XB82-XBU0-L5 (pink)
BB13-XBU0-0L (black) XB82-XBU0-L5 (black)
BB13-XBU0-0R (light blue) XB82-XBU0-R5 (light blue)
