Table B-12
Crossbar cable correspondence table (2 system of expansion rack 1) (continued)
Connected chassis SPARC M10-4S side Crossbar box side
BB13-XBU1-1R (light blue) XB83-XBU1-R5 (light blue)
BB13-XBU1-1R (black) XB83-XBU1-R5 (black)
BB13-XBU1-2L (pink) XB83-XBU2-L5 (pink)
BB13-XBU1-2L (black) XB83-XBU2-L5 (black)
BB13-XBU1-2R (light blue) XB83-XBU2-R5 (light blue)
BB13-XBU1-2R (black) XB83-XBU2-R5 (black)
BB#14 - XBBOX#83 BB14-XBU1-0L (pink) XB83-XBU0-L6 (pink)
BB14-XBU1-0L (pink) XB83-XBU0-L6 (black)
BB14-XBU1-0R (light blue) XB83-XBU0-R6 (light blue)
BB14-XBU1-0R (black) XB83-XBU0-R6 (black)
BB14-XBU1-1L (pink) XB83-XBU1-L6 (pink)
BB14-XBU1-1L (black) XB83-XBU1-L6 (black)
BB14-XBU1-1R (light blue) XB83-XBU1-R6 (light blue)
BB14-XBU1-1R (black) XB83-XBU1-R6 (black)
BB14-XBU1-2L (pink) XB83-XBU2-L6 (pink)
BB14-XBU1-2L (black) XB83-XBU2-L6 (black)
BB14-XBU1-2R
(light blue) XB83-XBU2-R6 (light blue)
BB14-XBU1-2R (black) XB83-XBU2-R6 (black)
BB#15 - XBBOX#83 BB15-XBU1-0L (pink) XB83-XBU0-L7 (pink)
BB15-XBU1-0L (black) XB83-XBU0-L7 (black)
BB15-XBU1-0R (light blue) XB83-XBU0-R7 (light blue)
BB15-XBU1-0R (black) XB83-XBU0-R7 (black)
BB15-XBU1-1L (pink) XB83-XBU1-L7 (pink)
BB15-XBU1-1L (black) XB83-XBU1-L7 (black)
BB15-XBU1-1R (light blue) XB83-XBU1-R7 (light blue)
BB15-XBU1-1R (black) XB83-XBU1-R7 (black)
BB15-XBU1-2L (pink) XB83-XBU2-L7 (pink)
BB15-XBU1-2L (black) XB83-XBU2-L7 (black)
BB15-XBU1-2R (light blue) XB83-XBU2-R7 (light blue)
BB15-XBU1-2R (black) XB83-XBU2-R7 (black)
Appendix B Cable Connection Information on Building Block Configurations 347
