Table B-13
Crossbar cable correspondence table (cables between the racks) (continued)
Connected chassis SPARC M10-4S side Crossbar box side
BB04-XBU0-1R (light blue) XB82-XBU1-R0 (light blue)
BB04-XBU0-1R (black) XB82-XBU1-R0 (black)
BB#04 - XBBOX#83 BB04-XBU1-1L (pink) XB83-XBU1-L0 (pink)
BB04-XBU1-1L (black) XB83-XBU1-L0 (black)
BB04-XBU1-1R (light blue) XB83-XBU1-R0 (light blue)
BB04-XBU1-1R (black) XB83-XBU1-R0 (black)
BB#05 - XBBOX#82 BB05-XBU0-1L (pink) XB82-XBU1-L1 (pink)
BB05-XBU0-1L (black) XB82-XBU1-L1 (black)
BB05-XBU0-1R (light blue) XB82-XBU1-R1 (light blue)
BB05-XBU0-1R (black) XB82-XBU1-R1 (black)
BB#05 - XBBOX#83 BB05-XBU1-1L (pink) XB83-XBU1-L1 (pink)
BB05-XBU1-1L (black) XB83-XBU1-L1 (black)
BB05-XBU1-1R (light blue) XB83-XBU1-R1 (light blue)
BB05-XBU1-1R (black) XB83-XBU1-R1 (black)
BB#06 -
XBBOX#82 BB06-XBU0-1L (pink) XB82-XBU1-L2 (pink)
BB06-XBU0-1L (black) XB82-XBU1-L2 (black)
BB06-XBU0-1R (light blue) XB82-XBU1-R2 (light blue)
BB06-XBU0-1R (black) XB82-XBU1-R2 (black)
BB#06 - XBBOX#83 BB06-XBU1-1L (pink) XB83-XBU1-L2 (pink)
BB06-XBU1-1L (black) XB83-XBU1-L2 (black)
BB06-XBU1-1R (light blue) XB83-XBU1-R2 (light blue)
BB06-XBU1-1R (black) XB83-XBU1-R2 (black)
BB#07 - XBBOX#82 BB07-XBU0-1L (pink) XB82-XBU1-L3 (pink)
BB07-XBU0-1L (black) XB82-XBU1-L3 (black)
BB07-XBU0-1R (light blue) XB82-XBU1-R3 (light blue)
BB07-XBU0-1R (black) XB82-XBU1-R3 (black)
BB#07 - XBBOX#83 BB07-XBU1-1L (pink) XB83-XBU1-L3 (pink)
BB07-XBU1-1L (black) XB83-XBU1-L3 (black)
BB07-XBU1-1R (light blue) XB83-XBU1-R3
(light blue)
BB07-XBU1-1R (black) XB83-XBU1-R3 (black)
Appendix B Cable Connection Information on Building Block Configurations 349
