A
REAR
PDU
PDU
B
Note -
Be careful when removing the side plate because it weighs about 13 kg.
Remarks -
Expansion rack 2 does not have the side plate.
Figure 3-3
Locations of the CB switches on the PDUs
2.
Remove the side plate on the right side as viewed from the front of the rack.
a. Remove the 10 screws securing the side plate.
b. Remove the side plate by lifting it up.
Chapter 3 Installing the System 77
