10 U41615-J-Z156-1-76
Technical Data Introduction
1.4 Technical Data
Electrical Data
Compliance Standards
Rated voltage range 100 V - 127 V or 200 V - 240 V
Rated frequency 50 Hz - 60 Hz
Rated current in basic configuration: 100 V - 127 V / 1.86 A
200 V - 240 V / 0.98 A
Max. rated current: 100 V - 127 V / 4 A
200 V - 240 V / 2 A
Active power 254 W
Apparent power 254 VA
Thermal dissipation 914.4 kJ/h (866.68 btu/h)
Main power fuse 16 A (6.3 A)
Protection class I
Product safety and ergonomics IEC 60950 / EN 60950, UL 1950 3rd. Ed.,
CAN/CSA 22.2 No. 60950 3rd. Ed.
Electromagnetic Compatibility
(standard power supply)
FCC class A
VCCI class A /JEIDA
CNS 13438 class A
C-Tick class A
Emitted interference EN 55022 class A
Harmonic current EN 61000-3-2
Flicker EN 61000-3-3
Noise immunity EN 55024
CE label
according to EU directives
Low-Voltage Directive 73/23/EEC
Electromagnetic Compatibility 89/336/EEC
