188
Chapter 7 Installing Internal Options
● Where to Install Server Control Cable
Connect the server control cable supplied with the Remote Service Board to the server control connector
as shown below.
When using the Remote Service Board, make sure to install ServerView.
[Rear]
Server control connector
PCI riser card
locking frame
Remote Service Board
Internal power connector
