Fujitsu Primergy RX100 S3 - Standard IDE Submenu

206
Chapter 8 Configuring Hardware and Utilities
8.1.3 Standard IDE Submenu
This submenu appears when selecting "Standard IDE" from the main menu.
Use this submenu to set the type and operating mode for connected IDE devices. When the drives are
installed to Standard IDE Master or Standard IDE Slave, each menu is displayed. Displayed items differ
from drive to drive.
table: Items on the Standard IDE Submenu
Item Setting Description
PIO Mode PIO 4 Displays the current PIO (Programmed I/O)
transfer mode. The fastest PIO transfer mode
among connected IDE devices is automatically set.
DMA Mode UDMA 2 Displays the current DMA (Direct Memory Access)
data transfer mode. The fastest DMA transfer mode
among connected IDE devices is automatically set.
Password Status Not Supported Displays the security information of connected hard
disk. This is not supported.
Change Password [Press Enter] Sets the hard disk password. If the hard disk
password is set, the password is required to start the
BIOS Setup Utility and the system. This is not
supported.
Item Specific HelpStandard IDE: [GCR-8483B-(PM)]
Select Item
Select Menu
Change Values
Select Sub-Menu
-/+
Enter
F1
Esc
Help
Exit
F9
F7
Setup Defaults
Previous Values
Advanced Security Server ExitMain
All item on this menu
cannot be modified in
user mode. If any
items require changes,
please consult your
system Supervisor.
PIO Mode:
DMA Mode:
Password Status:
Change Password:
PIO 4
UDMA 2
Not Supported
[Press Enter]
