Chapter 7 Installing Internal Options
7.6.2 Installable Internal Hard Disk Units
■ Installable Internal Hard Disk Units
The following internal hard disk units can be installed on this server.
Package
 Before installing the internal hard disk unit, refer to "Appendix B.4 Internal Hard Disk Unit
Specifications" (pg.277) to check the contents of the package.
■ Connections
The following shows connection of the internal hard disk unit.
table: List of Installable Hard Disk Units
Product name Model Overview
HDD U320 10k 73GB hot plug 1" PG-HDH71V 73.4GB, 10,000rpm,
3.5 inch, Ultra320 SCSI
HDD U320 10k 147GB hot plug 1" PG-HDH41V 146.8GB, 10,000rpm,
3.5 inch, Ultra320 SCSI
HDD U320 10k 300GB hot plug 1" PG-HDH31V 300GB, 10,000rpm,
3.5 inch, Ultra320 SCSI
Bay2
[Rear of the Server䌝
Bay1
SCSI cable䋺standard
Baseboard
Onboard SCSI connector
Backpanel
